Beechcraft King Air


Multirole Transport Aircraft [ 1964 ]



The Beechcraft King Air series began operations in 1964 and is still actively marketed today.



Authored By: Staff Writer | Last Edited: 11/04/2020 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

GO TO SPECIFICATIONS [+]
Advertisements
The Beechcraft King Air is a utility platform developed from the Beechcraft Queen Air of 1958. It continues to see flying time despite its Cold War-era roots. A prototype saw its first-flight in May of 1963 and the series was introduced on September 9th of 1964. Since then, some 3,100 examples have been produced and many offshoots have appeared for both military and civilian roles. The King Air was born as the company Model 120 in 1961.

The two primary models of the line are the Model 90 and Model 100 with a plethora of subvariants in between. The Model 100 has a lengthened fuselage with additional cabin viewing ports and an increased MTOW. Militarized forms are used United States (as the VC-6A, Pegasus and Ute) and others such as the Israeli Air Force (IAF), the Royal Canadian Air Force and the Japan Maritime Self Defense Force (JMSDF). Beyond this, the type has also been in service at the governmental level and under civilian operators globally. Former operators include Chile, Hong Kong, Ireland and Sweden.

The C90GTi model has a crew of one or two and can carry up to seven passengers. Overall length is 35.5 feet with a wingspan of 50.2 feet and a height of 14.2 feet. Empty weight is 7,000lb against an MTOW of 10,100lb. Power is from 2 x Pratt & Whitney Canada PT6A-135A series turboprop engines outputting 550 horsepower each and driving Hartzell propeller units. Performance includes a maximum speed of 311 miles per hour, a cruising speed of 260 mph, a range out to 1,530 miles and a service ceiling up to 30,000 feet. Rate-of-climb is 2,000 feet-per-minute.

The B100 model switches to 2 x Garrett TPE-331-6-251B or -252 series turboprop engines of 840 horsepower output. Speed is slightly decreased (307mph) as is the service ceiling (24,850 feet).

Variants in the King Air line include the "Super King Air" of 1972, also taken into civilian and military circles with nearly 4,000 units produced.©MilitaryFactory.com
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.

December 2018 - The United States Army is in the market to replace its aging fleet of C-12 and C-26 fixed-wing aircraft; the King Air CER is said to be a contender.

December 2018 - Raytheon UK has been awarded an eleven-year support contract for the Beechcraft Shadow R1 (King Air 350CER) surveillance platform operated by the Royal Air Force (out of Waddington, Lincolnshire).

August 2020 - The French Air Force has taken delivery of a pair of King Air 350 aircraft to satisfay a standing Intelligence-Surveillance-Reconnaissance (ISR) requirement.

Advertisements

Specifications



Service Year
1964

Origin
United States national flag graphic
United States

Status
ACTIVE
In Active Service.
Crew
2

Production
3,120
UNITS


National flag of Algeria National flag of Argentina National flag of Australia National flag of Bolivia National flag of Canada National flag of Chile National flag of Colombia National flag of Ecuador National flag of France National flag of Greece National flag of India National flag of Iraq National flag of modern Japan National flag of Mexico National flag of Morocco National flag of Peru National flag of South Africa National flag of Spain National flag of Sri Lanka National flag of the United Kingdom National flag of the United States National flag of Uruguay National flag of Venezuela Argentina; Algeria; Australia; Barbados; Bolivia; Canada; Chile; Colombia; Ecuador; France; Greece; Guatemala; India; Iraq; Ivory Coast; Mexico; Jamaica; Japan; Morocco; Peru; South Africa; Sri Lanka; Spain; United Kingdom; United States; Venezuela; Uruguay
(OPERATORS list includes past, present, and future operators when applicable)
Transport
General transport functionality to move supplies/cargo or personnel (including wounded and VIP) over range.
Commercial Aviation
Used in roles serving the commercial aviation market, ferrying both passengers and goods over range.
VIP Service
Used in the Very-Important-Person (VIP) passenger transport role, typically with above-average amenities and luxuries as standard.
Training (General)
Developed ability to be used as a dedicated trainer for student pilots (typically under the supervision of an instructor).


Length
35.5 ft
(10.82 m)
Width/Span
50.3 ft
(15.32 m)
Height
14.2 ft
(4.34 m)
Empty Wgt
6,945 lb
(3,150 kg)
MTOW
10,097 lb
(4,580 kg)
Wgt Diff
+3,153 lb
(+1,430 kg)
(Showcased structural values pertain to the Beechcraft King Air C90GTi production variant)
Installed: 2 x Pratt & Whitney Canada PT6A-135A turboprop engines developing 550 horsepower.
Max Speed
311 mph
(500 kph | 270 kts)
Ceiling
30,000 ft
(9,144 m | 6 mi)
Range
1,520 mi
(2,446 km | 4,530 nm)
Rate-of-Climb
2,000 ft/min
(610 m/min)


♦ MACH Regime (Sonic)
Sub
Trans
Super
Hyper
HiHyper
ReEntry
RANGES (MPH) Subsonic: <614mph | Transonic: 614-921 | Supersonic: 921-3836 | Hypersonic: 3836-7673 | Hi-Hypersonic: 7673-19180 | Reentry: >19030


(Showcased performance specifications pertain to the Beechcraft King Air C90GTi production variant. Performance specifications showcased above are subject to environmental factors as well as aircraft configuration. Estimates are made when Real Data not available. Compare this aircraft entry against any other in our database or View aircraft by powerplant type)
None. Military forms carry special mission equipment for Intelligence-Surveillance-Reconnaissance (ISR) sorties.


Supported Types




(Not all ordnance types may be represented in the showcase above)
King Air - Base Series Designation.
Model 87 - Developmental Test Vehicle; 2 x PT6A-6 turboprop engines.
Model 65-90 - Initial production model; 2 x PT6A-6 turboprop engines; 112 examples produced.
Model 65-A90 - Revised cockpit; engine de-icing integrated; increased MTOW.
Model 65-A90-1 - 2 x PT6A-20 turboprop engines; unpressurized cockpit/cabin.
Model 65-A90-2 - Electronic Warfare Aircraft (EWA)
Model 65-A90-3 - Improved EWA version
Model 65-A90-4 - Reinforced airframe; increased MTOW; 16 examples completed.
Model B90 - Revised wings; increased MTOW; revised cockpit; 184 examples produced.
Model C90 - 2 x PT6A-21 turboprop engines; cabin pressurization of Model 100 series; 507 examples produced.
Model C90-1 - Improved C90 model; 54 examples produced.
Model C90A - 2 x PT6A-21 turboprop engines; revised undercarriage.
Model C90B - Updated C90A models; increased MTOW
Model C90SE - Alternative C90A updated models
Model C90GT - 2 x PT6A-135A engines of 750 horsepower; 97 examples produced.
Model C90GTi - Updated C90GT form with digital glass cockpit; 90 examples produced.
Model C90GTx - Modified C90GT with added winglets; increased MTOW.
Model D90 - Incomplete prototype initiative
Model E90 - 2 x PT6A-28 engines of 680 horsepower; 347 examples produced.
Model F90 - 2 x PT6A-135 engines of 750 horsepower; four-bladed propeller assemblies; T-style tail assembly; 196 produced.
Model F90-1 - Model F90 with 2 x PT6A-135A engines; 32 examples produced.
Model G90
Model H90
Model 100
Model A100
Model B100
Model A100-1
YU-21
U-21A Ute
EU-21A
JU-21A
RU-21A
RU-21B
RU-21C
RU-21D
RU-21E
U-21F
U-21G Ute
RU-21G
RU-21H
U-21H
U-21H Ute
JU-21H
VC-6A
T-44A Pegasus - U.S. Navy crew/systems trainer.
T-44C Pegasus - U.S. Navy crew/systems trainer (upgraded).
Super King Air - Model of 1972; covers Model 200 and Model 300 series.
Shadow R1 - Surveillance platform based in the King Air 350ER.


Military lapel ribbon for Operation Allied Force
Military lapel ribbon for the Arab-Israeli War
Military lapel ribbon for the Battle of Britain
Military lapel ribbon for the Battle of Midway
Military lapel ribbon for the Berlin Airlift
Military lapel ribbon for the Chaco War
Military lapel ribbon for the Cold War
Military lapel ribbon for the Cuban Missile Crisis
Military lapel ribbon for pioneering aircraft
Military lapel ribbon for the Falklands War
Military lapel ribbon for the French-Indochina War
Military lapel ribbon for the Golden Age of Flight
Military lapel ribbon for the 1991 Gulf War
Military lapel ribbon for the Indo-Pak Wars
Military lapel ribbon for the Iran-Iraq War
Military lapel ribbon for the Korean War
Military lapel ribbon for the 1982 Lebanon War
Military lapel ribbon for the Malayan Emergency
Military lapel ribbon representing modern aircraft
Military lapel ribbon for the attack on Pearl Harbor
Military lapel ribbon for the Six Day War
Military lapel ribbon for the Soviet-Afghan War
Military lapel ribbon for the Spanish Civil War
Military lapel ribbon for the Suez Crisis
Military lapel ribbon for the Ukranian-Russian War
Military lapel ribbon for the Vietnam War
Military lapel ribbon for Warsaw Pact of the Cold War-era
Military lapel ribbon for the WASP (WW2)
Military lapel ribbon for the World War 1
Military lapel ribbon for the World War 2
Military lapel ribbon for the Yom Kippur War
Military lapel ribbon for experimental x-plane aircraft


Ribbon graphics not necessarily indicative of actual historical campaign ribbons. Ribbons are clickable to their respective aerial campaigns / operations / aviation periods.

Images Gallery



1 / 7
Image of the Beechcraft King Air
