de Havilland Canada DHC-4 Caribou


Tactical Transport Aircraft [ 1959 ]



The United States military was the primary user of the Canadian Caribou aircraft - which went on to serve with distinction in the Vietnam War.



Authored By: Staff Writer | Last Edited: 08/30/2017 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

VIEW SPECIFICATIONS [+]
The Caribou series proved to be such an effective battlefield transport aircraft that more than a few were pressed into service as captured C-7's in the hands of the North Vietnamese. The type continues to serve in limited numbers and was seen in action as recent as 2000 with Australian forces in East Timor. By 1973, the Caribou series would see over 300 examples produced.

The Caribou was a twin-engine design undertaken by de Havilland Canada as a private project with hopes of enticing the military forces of both Canada and the United States of America. The initial design was designated as the DHC-4 and was engineered with short take-off and landing (STOL) capabilities in mind and was a naturally rugged design to boot, making most enticing to the United States Army, which went on to order five evaluation models as the YAC-1. From there, the Caribou emerged as a production model in the AC-1 series which would later become the CV-2. By the time the United States Air Force took over control of the Caribou aircraft in early 1967, the designation was changed once again to the more identifiable C-7 series.©MilitaryFactory.com
At its core, the Caribou was powered by two Pratt & Whitney brand engines generating 1,450shp (DHC-4). Engines were mounted on a high-wing / straight-wing monoplane assembly allowing for optimal ground clearance around the fuselage and especially the three-bladed propeller systems. A large cargo hold door was mounted to the rear part of the main fuselage with the single-rudder tail assembly extending past and over the loading area door. Hold capabilities were very generous and could allow for the transport of 32 troops, 22 medevac litters, 2 vehicles or up to 4 tons of cargo in the form of equipment, supplies or artillery systems.

In the end, the United States became the largest operator of the Caribou system in operation with both the United States Army and the United States Air Force. Australia also operated (and in some cases continues to do so) the type along with Canada, Spain, Columbia and India among others. The system proved quite capable in the rugged Vietnamese battlefront and was a highly prized vehicle for having the ability to land on short airstrips to deliver supplies / manpower and retrieve the wounded.©MilitaryFactory.com
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.

Specifications



Service Year
1959

Origin
Canada national flag graphic
Canada

Crew
3 + 32

Production
307
UNITS


de Havilland Aircraft of Canada, LTD - Canada
(View other Aviaton-Related Manufacturers)
National flag of Australia National flag of Canada National flag of India National flag of Malaysia National flag of Spain National flag of Tanzania National flag of the United States National flag of Vietnam Australia; Costa Rica; Liberia; Malaysia; Canada; Columbia; India; Spain; Tanzania; North Vietnam; United States
(OPERATORS list includes past, present, and future operators when applicable)
Transport
General transport functionality to move supplies/cargo or personnel (including wounded and VIP) over range.


Length
72.6 ft
(22.13 m)
Width/Span
95.6 ft
(29.15 m)
Height
31.8 ft
(9.68 m)
Empty Wgt
18,283 lb
(8,293 kg)
MTOW
31,295 lb
(14,195 kg)
Wgt Diff
+13,012 lb
(+5,902 kg)
(Showcased structural values pertain to the de Havilland Canada DHC-4A Caribou production variant)
Installed: 2 x Pratt & Whitney R-2000-7M2 14-cylinder twin row radial piston engines developing 1,450 shp.
Max Speed
216 mph
(347 kph | 187 kts)
Ceiling
24,800 ft
(7,559 m | 5 mi)
Range
1,308 mi
(2,105 km | 1,137 nm)
Rate-of-Climb
1,355 ft/min
(413 m/min)


♦ MACH Regime (Sonic)
Sub
Trans
Super
Hyper
HiHyper
ReEntry
RANGES (MPH) Subsonic: <614mph | Transonic: 614-921 | Supersonic: 921-3836 | Hypersonic: 3836-7673 | Hi-Hypersonic: 7673-19180 | Reentry: >19030


(Showcased performance specifications pertain to the de Havilland Canada DHC-4A Caribou production variant. Performance specifications showcased above are subject to environmental factors as well as aircraft configuration. Estimates are made when Real Data not available. Compare this aircraft entry against any other in our database or View aircraft by powerplant type)
None.


Supported Types




(Not all ordnance types may be represented in the showcase above)
YAC-1 - US Army Evaluation Model Designation of which 5 examples were ordered.
AC-1A - Initial Production Model Designation later changed to CV-2B, then to C-7A.
CV-2B - US Army Series Designation
C-7A - US Air Force Series Designation
DHC-4A - Australian Base Model Series Designation.
