Infantry Small Arms / The Warfighter

Colt M16A2


Assault Rifle [ 1983 ]



The M16A2 improved upon many of the limitations encountered in the original Vietnam War-era M16 Assault Rifle.



Authored By: Staff Writer | Last Edited: 06/08/2022 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

GO TO SPECIFICATIONS [+]
Advertisements
The M16A2 became the follow up design to the much-maligned M16 debuting with American forces from 1959 onwards (particularly during the Vietnam War). The model was developed to a United States Marine Corps (USMC) request after combat experiences with the prototype XM16E1 and production-quality M16A1 models proved highly vulnerable to battlefield abuses. The M16A2, therefore, became a major reworking of the original and included changes such as new rifling patterns on the barrel assemblies as well as reinforced barrels, support for the single-shot 40mm M203 underslung grenade launcher, an all-new adjustable rear sight installation, a revised flash suppressor less prone to collecting debris, a reworked rounded/ribbed frontal handguard (as opposed to triangular), slightly revised ergonomic pistol grip, lengthened and reinforced shoulder stock of polymer with integrated buttplate and a shell deflector fitted along the right side of the receiver near the ejection port. The full-automatic fire functionality of the original M16 was dropped in preference for a more controllable three-round burst fire mode along with the standard semi-automatic fire. Muzzle climb has been substantially reduced and use of plastics has made for a lightened end-product. The USMC was the first US service branch to adopt the improved M16A2 in the mid-1980s with other service branches following suit. The M16A2 has, itself, since been replaced by the equally-improved M16A4 though it still sees widespread circulation in US inventories and her allies the world over.

Despite the laundry list of changes, the M16A2 does retain the tried-and-true gas-operated, direct impingement rotating bolt system of the original M16. It also fires the 5.56x45mm NATO standard cartridge though from a longer, curved 30-round detachable box magazine. It keeps the general (and highly identifiable) M16/AR-15 shape which includes its two-piece (upper and lower) receiver system, standalone pistol grip with integrated trigger group, a handguard shrouding the gas system and a portion of the barrel and the triangular shoulder stock. Sling loops provide use of a shoulder strap for transport. The carrying handle loop is also slightly larger. The charging handle remains at the rear of the upper receiver.

The M16A3 mark brought about in 1996 was developed to cover a full-automatic variant of the M16A2 with the trigger group of the M16A1 allowing for semi- and full-automatic fire modes. A removable carrying handle allowed for use of various optics and aimers. Production was limited and its adoption was equally limited to special units. The M231 became another M16-related form, this as a stripped down M16 intended for port-firing from vehicles. Though never having entered production, Colt Advanced Combat Rifle (ACR) was tested to the extreme as the next-generation infantry weapon for the US Army. The ACR shared the common M16 "look" and was built from the existing M16A2 production model. The M4 Carbine is nothing more than a compact variant of the M16 line - based on the evolutionary M16A2 model.

The M16A4 differs from preceding M16 forms in that it has a removable carrying handle to accommodate for mounted accessories such as an optical sights. The barrel is also designed to mount the 40mm M203 grenade launcher.

The M16 has seen production by Colt Defense, Daewoo Precision Industries (South Korea), FN Herstal (Belgium), H&R Firearms, General Motors Hydramatic Division, Elisco and U.S. Ordnance. Over 10 million M16 units (including all deviations) have been produced since 1959. The weapon has seen combat actions through the Vietnam War (and its subsequent regional civil wars), Grenade, Panama, the 1991 Gulf War, the Somali Civil War and - most recently - in the American-led invasions of Afghanistan and Iraq following the events of 9/11.©MilitaryFactory.com
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.
Advertisements

Specifications



Service Year
1983

Origin
United States national flag graphic
United States

Classification


Assault Rifle


Colt Defense / General Motors / H&R Firearms - USA; FN Herstal - Belgium
(View other Arms-Related Manufacturers)
National flag of Afghanistan National flag of Argentina National flag of Australia National flag of Bahrain National flag of Bangladesh National flag of Bolivia National flag of Bosnia and Herzegovina National flag of Brazil National flag of Cameroon National flag of Canada National flag of Chile National flag of Colombia National flag of Cyprus National flag of Denmark National flag of the Dominican Republic National flag of Egypt National flag of France National flag of Georgia National flag of Greece National flag of Iceland National flag of India National flag of Indonesia National flag of Iraq National flag of Israel National flag of Italy National flag of modern Japan National flag of Jordan National flag of Kuwait National flag of Lebanon National flag of Malaysia National flag of Mexico National flag of Morocco National flag of the Netherlands National flag of New Zealand National flag of Nicaragua National flag of Nigeria National flag of Oman National flag of Pakistan National flag of Peru National flag of the Philippines National flag of Portugal National flag of Qatar National flag of the Kingdom of Saudi Arabia National flag of Singapore National flag of South Korea National flag of Sri Lanka National flag of Taiwan National flag of Thailand National flag of Turkey National flag of Tunisia National flag of the United Arab Emirates National flag of the United Kingdom National flag of the United States National flag of Uruguay National flag of Vietnam National flag of Venezuela National flag of Yemen National flag of Zaire Afghanistan; Argentina; Australia; Bahamas; Bangladesh; Bahrain; Barbados; Belize; Bolivia; Brazil; Botswana; Bosnia and Herzegovina; Brunei; Cambodia; Cameroon; Canada; Chile; Colombia; Costa Rica; Cyprus; Denmark; Dominican Republic; Egypt; Estonia; El Salvador; Fiji; France; Georgia; Ghana; Greece; Grenada; Guatemala; Haiti; Honduras; Iceland; India; Indonesia; Iraq; Israel; Italy; Japan; Jordan; Jamaica; Kuwait; Laos; Latvia; Lebanon; Lesotho; Liberia; Liechtenstein; Maldives; Malaysia; Mexico; Morocco; Nepal; New Zealand; Nigeria; Netherlands; Nicaragua; Oman; Pakistan; Papua New Guinea; Panama; Peru; Philippines; Portugal; Qatar; Saudi Arabia; Singapore; Sri Lanka; South Korea; Rhodesia; Taiwan; Thailand; Timor-Leste; Tunisia; Turkey; United Arab Emirates; United Kingdom; United States; Uruguay; Venezuela; Vietnam; Yemen; Zaire
(OPERATORS list includes past, present, and future operators when applicable)
Automatic Function
Features a mechanical function to automate the firing action.
Assault Rifle
Modern class of long gun featuring select-fire properties, automatic internal function, and magazine feeding.
Special Forces
Qualities of this weapon have shown its value to Special Forces elements requiring a versatile, reliable solution for the rigors of special assignments.


Overall Length
1,000 mm
39.37 in
Barrel Length
508 mm
20.00 in
Empty Wgt
7.89 lb
3.58 kg
Sights


Ajustable Rear; Fixed Front; Optional Optics


Action


Gas-Operated; Semi-Automatic; Select Fire

Semi-Automatic
One shot per trigger pull; self-loading or auto-loading action aided by internal mechanism; trigger management (and initial cocking) typically required by the operator; subsequent shots are aided by the unlocked / moved bolt.
Gas-Operated
Gas-operated system is featured, typically involving a gas cylinder and rear-driven piston directing energy to the bolt component.
(Material presented above is for historical and entertainment value and should not be construed as usable for hardware restoration, maintenance, or general operation - always consult official manufacturer sources for such information)


Caliber(s)*


5.56x45mm NATO

Sample Visuals**


Graphical image of a 5.56mm intermediate rifle cartridge
Rounds / Feed


30-round detachable box magazine
Cartridge relative size chart
*May not represent an exhuastive list; calibers are model-specific dependent, always consult official manufacturer sources.
**Graphics not to actual size; not all cartridges may be represented visually; graphics intended for general reference only.
Max Eff.Range
1,969 ft
(600 m | 656 yd)
Rate-of-Fire
800
rds/min
Muzzle Velocity
3,050 ft/sec
(930 m/sec)


AR-15 - Armalite Designation
Model 601 - Colt Model; adapted by the USAF; 1:14-inch rifling twist; triangular charging handle.
Model 602 - Colt Model Designation; 1:12-inch twist; triangular charging handle.
Model 604 - Colt Model Designation; improved model.
Model 655 M16A1 SHP (Special High Profile) - Colt Model Designation for sniper variant; heavy barrel and Leatherwood/Realist 3.9x Adjustable Ranging Telescope scope mount.
Model 656 - Colt Model Designation for sniper variant; heavy barrel and Leatherwood/Realist 3.9x Adjustable Ranging Telescope scope mount; sans carrying handle.
Model 720 - Cold Model Designation of the XM4/M4 Carbine variant.
Model 733 - Developmental M16 carbine version with shortened barrel and telescoping stock; modernized version of the XM177E2 with improvements found on the M16A2.
XM-16 - Alternative designation for Colt Model 602.
M16 - Base Production Model Designation; first operation version; adapted by the USAF.
XM16E1 - US Army Designation of the M16
M16A1 - US Army Finalized Production Model
M16A1 Mk 4 Mod 0 - Specialized Variant produced for the Navy SEALs; optimized for "wet" environments; sound suppressor.
M16A2 - Revised rifling; thicker barrel; M203 grenade launcher capable; square post front sight; adjustable rear sight added; revised flash suppressor; modified front grip; lengthened buttstock; polymer stock; 3-round burst setting.
M16A3 - Fully-Automatic derivative of the M16A2; M16A1 trigger group; semi-automatic and full automatic fire modes.
M16A4 / M16A4 MWS- Picatinny Rail for scope and sighting systems; 3-round burst firing mode of the M16A2 accessory attachments through Knight's Armament Company system; sometimes called M16A4 MWS (Modular Weapon System).
XM177E1 - Developmental M16 carbine version; shortened barrel to 10 inches; telescoping stock.
XM177E2 - Developmental M16 carbine version; shortened barrel to 11 inches; telescoping stock.
M231 FPW (Port Firing Weapon) - Rock Island Arsenal development based on M16 for firing from the inside of the M2/M3 Bradley vehicles; fully-automatic fire form open bolt; sans buttstock; short barrel.
XM4 Carbine - Trials version of compact M16 rifle.
M4 Carbine - Production designation of compact M16 rifle; 3-round burst fire mode; Picatinny rail system; removable carrying handle.
M4A1 Carbine - Full Automatic Fire Mode; Picatinny rail system; removable carrying handle.
C7 - Canadian Designation; production by Diemaco; developed version of the M16A1E1; single or automatic fire modes; lengthened stock; revised rear sight.
C7A1 - Canadian Designation; Weaver rail system; improvements throughout
C8 - Canadian Designation; updated M16 variant.
NORINCO CQ-311 - Unlicensed Chinese copy of the M16A1; revolver-style pistol grip; export product.
Khaybar KH2002 - Iranian conversion model based on the S-5 rifle, itself an M16 copy based on the NORINCO model; bullpup configuration.
MSSR - Philippine development sniper rifle based on the M16.
Type 65 (T65) - Taiwanese Assault Rifle based on the M16; short-stroke gas system; revised iron sights; reshaped stock
Type 86 (T86) - Taiwanese Assault Rifle based on the M16; gas-operated, rotating bolt; M16A2-style sights.
Type 91 (T91) - Taiwanese Assault Rifles based on the M16; gas-operated, rotating bolt; features found on the M16 and AR-18 series rifles.
M/95 - Danish Designation of Canadian C7 rifle.
M/96 - Danish Designation of Canadian C8 rifle.


Military lapel ribbon for the American Civil War
Military lapel ribbon for pioneering aircraft
Military lapel ribbon for the Cold War
Military lapel ribbon for the Korean War
Military lapel ribbon representing modern aircraft
Military lapel ribbon for the Ukranian-Russian War
Military lapel ribbon for the Vietnam War
Military lapel ribbon for the World War 1
Military lapel ribbon for the World War 2


Ribbon graphics not necessarily indicative of actual historical campaign ribbons. Ribbons are clickable to their respective campaigns / operations.

Images Gallery



1 / 13
Image of the Colt M16A2
Image copyright www.MilitaryFactory.com; No Reproduction Permitted.
2 / 13
Image of the Colt M16A2
US soldiers on a live-fire range with their Colt M16A2 automatic rifles
3 / 13
Image of the Colt M16A2
Soldiers take aim with unloaded Colt M16A2 automatic rifles
4 / 13
Image of the Colt M16A2
US Army soldiers attend to their Colt M16A2 automatic rifles
5 / 13
Image of the Colt M16A2
Line drawings showcasing left and right side views of the Colt M16A2 automatic rifle
6 / 13
Image of the Colt M16A2
An unloaded Colt M16A2 automatic rifle
7 / 13
Image of the Colt M16A2
Right side profile view of an unloaded Colt M16A2 automatic rifle
8 / 13
Image of the Colt M16A2
Close-up detail view of the magazine, ejection port and carrying handle of a Colt M16A2 automatic rifle
9 / 13
Image of the Colt M16A2
A soldier tracks a target through the scope atop his Colt M16A2 automatic rifle
10 / 13
Image of the Colt M16A2
Close-up detail view of the trigger group and rear sight of a Colt M16A2 automatic rifle
11 / 13
Image of the Colt M16A2
Close-up detail of the right side of a Colt M16A2 automatic rifle
12 / 13
Image of the Colt M16A2
A soldier takes careful aim with his Colt M16A2 automatic rifle; note scope in place of carrying handle
13 / 13
Image of the Colt M16A2
Right side profile view of the Colt M16A2 automatic rifle
