Kaiser-Jeep M715 (Five Quarter)


1.25-ton Utility Truck [ 1967 ]



Kaiser Jeep of Toledo, Ohio, produced some 33,000 of its M715 and derivative utility vehicles over a two-year span.



Authored By: Staff Writer | Last Edited: 05/16/2016 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

VIEW SPECIFICATIONS [+]
Up to 1965, the United States military relied on the Dodge G741 truck (as the M37) as its go anywhere, do anything truck. 115,838 of this vehicle were ultimately procured from 1951 to 1968 and many variants of the base design emerged over the course of its service tenure. However, this product's long term cost was growing prohibitive and forced authorities to consider a less expensive alternative going forward. The decision was made to pursue a civilian design already in circulation that could meet the military requirement and this set the focus on the Kaiser-Jeep "Gladiator" - a 4x4 wheeled 1.25-ton general purpose pickup truck. The move spawned the M715 family of military trucks which included three other major variants.

The vehicle was trialled by the Armor and Engineer Board of Fort Knox, Kentucky during late 1966 (as the XM715). The M715 was to retain much of its civilian origins, making it a lower cost affair than previous U.S. military truck offerings in that common, off-the-shelf components could be used for repairs and overhauls. A key change to the XM715 from its Gladiator days was an open-top cab which required modification to the doors and (naturally) the cab roof itself. The forward windscreen was hinged to fold down over the engine hood, reminiscent of the classic U.S. Army JEEPs. The canvas top set over the cab was removable. The forward fenders were resized to accept military-grade road wheels. The vehicle took on a conventional arrangement with driver at front-left, the engine compartment at front, and the cargo bed over the rear. The cab seated only two across as the large battery box ran between the two seats. The cargo area was spartan with only the wheel wells taking up any permanent space.

The initial production contract for Kaiser-Jeep called for 20,680 vehicles in March 1966. Production began in 1967 and that same year also saw first deliveries. Manufacture lasted until 1969 out of the Kaiser-Jeep plant in Toledo, Ohio with 30,500 units delivered in all.

There proved four major variants of the M715 line beginning with the M715 standard cargo/troop carrier. A winch was optional with this model. The M724 "contact maintenance truck" was simply the M715 with only the cab and chassis while lacking the cargo bed and fitting a combination welder/generator and winch. The M725 was an ambulance with an enclosed rear structure for four patient litters and medical staff. Double doors provided rear access and the cab and rear section were joined by a sliding door. A floodlight was fitted over the forward windscreen. The M726 "telephone maintenance truck" was built on the same chassis as the M724 and resembled a civilian telephone service personnel's truck. Its cargo area consisted of storage compartments fitted over the wheel wells with an open space between them. Some of this model were also seen with spotlights and winch systems.

M715 trucks saw service in the Vietnam War (1955-1975) and was also deployed along the Korean Demilitarized Zone (DMZ) and across Europe.©MilitaryFactory.com
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.

Specifications



Service Year
1967

Origin
United States national flag graphic
United States

Crew
1
CREWMEN
Production
30,500
UNITS


Kaiser-Jeep Corporation - USA
(View other Vehicle-Related Manufacturers)
National flag of the United States United States
(OPERATORS list includes past, present, and future operators when applicable)
Utility
General utility-minded design to accomplish a variety of battlefield tasks, typically in a non-direct-combat fashion.


Length
18.4 ft
5.6 m
Width
7.2 ft
2.2 m
Height
6.6 ft
2 m
Weight
8,400 lb
3,810 kg
Tonnage
4.2 tons
LIGHT
(Showcased structural values pertain to the base Kaiser-Jeep M715 (Five Quarter) production variant. Length typically includes main gun in forward position if applicable to the design)
Powerplant: 1 x Tornado inline 6-cylinder gasoline engine developing 133 horsepower.
Speed
55.3 mph
(89.0 kph)
Range
224.9 mi
(362.0 km)
(Showcased performance specifications pertain to the base Kaiser-Jeep M715 (Five Quarter) production variant. Compare this entry against any other in our database)
None - save for personal weapons carried by the crew.


Supported Types


Graphical image of the M3 Grease Gun submachine gun


(Not all weapon types may be represented in the showcase above)
Dependent upon weapons carried.


M715 - Base Personnel / Cargo Carrier
M724 - Cab and chassis variant
M725 - Ambulance
M726 - Telephone Maintenance Truck


Military lapel ribbon for the American Civil War
Military lapel ribbon for pioneering aircraft
Military lapel ribbon for the Arab-Israeli War
Military lapel ribbon for the Battle of the Bulge
Military lapel ribbon for the Battle of Kursk
Military lapel ribbon for the Cold War
Military lapel ribbon for the Falklands War
Military lapel ribbon for the Indo-Pak Wars
Military lapel ribbon for the Korean War
Military lapel ribbon for the 1991 Gulf War
Military lapel ribbon representing modern aircraft
Military lapel ribbon for the Soviet-Afghan War
Military lapel ribbon for the Spanish Civil War
Military lapel ribbon for the Ukranian-Russian War
Military lapel ribbon for the Vietnam War
Military lapel ribbon for the World War 1
Military lapel ribbon for the World War 2
Military lapel ribbon for the Yom Kippur War
Military lapel ribbon for experimental military vehicles


Ribbon graphics not necessarily indicative of actual historical campaign ribbons. Ribbons are clickable to their respective campaigns / operations.

Images Gallery



1 / 10
Image of the Kaiser-Jeep M715 (Five Quarter)
