Cannone da 47/32 M35


Anti-Tank Gun / Infantry Gun [ 1935 ]



The 47mm M35 anti-tank gun served with Italian infantry and paratrooper units during the fighting of World War 2.



Authored By: Staff Writer | Last Edited: 10/08/2018 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

GO TO SPECIFICATIONS [+]
Advertisements
Based on an original Austrian design (by Bohler), the Cannone da 47/32 M35 was an Italian licensed-produced, local copy of the anti-tank/infantry field gun for the Army. It fired a 47mm HEAT (High-Explosive, Anti-Tank) and AP (Armor-Piercing) projectile capable of penetrating light-class vehicles. The gun proved so efficient that it made up the main armament of the guns seen in the Autoblinda AB 41 series armored car, the Carro Armato M15/42 Medium Tank and the Semovente 47/32 Self-Propelled Gun (SPG) platform.

The M35 was given a conventional artillery piece arrangement, mounting the 47mm caliber with 32-caliber-lengths gun barrel (hence the "47/32" in the designation) to a mounting system. The recoil mechanism was integrated. Split-trail tow arms were also used to take on some of the recoil forces. The tow arms then came together when the weapon system was to be moved by vehicle. In its combat stance, the weapon weighed 610lbs. Its travel weight was listed at 700lbs. Overall length of the system was 5 feet, 6 inches.

The mounting hardware allowed for an inherent elevation range of -15 to +56 degrees with a 62-degree limited traverse (using the supplied hand wheels). Muzzle velocity of the exiting projectile was 2,065 feet per second when using the standard AP round (the HEAT round measured a much controlled 820 feet per second). Maximum range was out to 7,700 yards and armor penetration of 58mm could be reached out to 100 meters with the AP projectile.

Initial production marks (Mod.35) featured semi-pneumatic disk-type wheels. It was not until 1939 that a slightly new mark appeared, this as the Mod.39 with a revised wheel design.

Captured Italian guns (following the 1943 Italian September surrender) in German service were designated as 4.7cm PaK 177(i) - the lowercase "i" to indicate their Italian origins.©MilitaryFactory.com
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.
Advertisements

Specifications



Service Year
1935

Origin
Italy national flag graphic
Italy

Crew
5
CREWMEN
Production
600
UNITS


National flag of Austria National flag of China National flag of Finland National flag of modern Germany National flag of Nazi Germany National flag of Italy National flag of the Kingdom of Italy National flag of the Netherlands National flag of Romania National flag of the Soviet Union National flag of Switzerland Austria; China; Estonia; Finland; Kingdom of Italy; Latvia; Nazi Germany; Netherlands; Romania; Soviet Union; Switzerland
(OPERATORS list includes past, present, and future operators when applicable)
Fire Support / Assault / Breaching
Support allied forces through direct / in-direct fire, assault forward positions, and / or breach fortified areas of the battlefield.


Length
5.5 ft
1.68 m
Weight
661 lb
300 kg
(Showcased structural values pertain to the base Cannone da 47/32 M35 production variant. Length typically includes main gun in forward position if applicable to the design)
1 x 47mm main gun barrel


Supported Types


Graphical image of a tank cannon armament
Graphical image of an artillery gun tube/barrel


(Not all weapon types may be represented in the showcase above)
Dependent on ammunition carrier.


Cannone da 47/32 M35 - Base Series Designation
Mod.35 - Original Production Mark of 1935
Mod.39 - Revised wheels; mark of 1939


Military lapel ribbon for the American Civil War
Military lapel ribbon for pioneering aircraft
Military lapel ribbon for the Arab-Israeli War
Military lapel ribbon for the Battle of the Bulge
Military lapel ribbon for the Battle of Kursk
Military lapel ribbon for the Cold War
Military lapel ribbon for the Falklands War
Military lapel ribbon for the Indo-Pak Wars
Military lapel ribbon for the Korean War
Military lapel ribbon for the 1991 Gulf War
Military lapel ribbon representing modern aircraft
Military lapel ribbon for the Soviet-Afghan War
Military lapel ribbon for the Spanish Civil War
Military lapel ribbon for the Ukranian-Russian War
Military lapel ribbon for the Vietnam War
Military lapel ribbon for the World War 1
Military lapel ribbon for the World War 2
Military lapel ribbon for the Yom Kippur War
Military lapel ribbon for experimental military vehicles


Ribbon graphics not necessarily indicative of actual historical campaign ribbons. Ribbons are clickable to their respective campaigns / operations.

Images Gallery



1 / 1
Image of the Cannone da 47/32 M35
