Aviatik C.I


Reconnaissance Biplane Aircraft [ 1915 ]



The German Aviatik C.I was designed from the outset with military use in mind, sporting a single 7.92mm Parabellum machine gun for self-defense.



Authored By: Staff Writer | Last Edited: 07/31/2019 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

GO TO SPECIFICATIONS [+]
Advertisements
Aviatik (Automobil und Aviatikwerke) of Germany was already involved in aircraft designs from the outset of the war, graduating from the copying of French designs to producing their own new design in the Aviatik B.I. Following that, Aviatik produced their first full military-ready design in the Aviatik C.I series, a biplane reconnaissance aircraft that would serve effectively along the Front.

The C.I was a single-engine, twin-seat biplane with a Mercedes D.II 6-cylinder engine producing upwards of 120 horsepower and driving a two-blade propeller. The system followed suit with the previous B.I in that the observer was seated in the front - just behind the engine - and the pilot was at rear. This time, the forward observer was afforded a single 7.92mm Parabellum machine gun on a flexible mounting. Though in theory, this seemed to improve upon the previous B.I system, it was soon found that the field of fire for the observer was quite restricted and the rearward seating position of the pilot was ill-suited when compared to other aircraft types coming out at the time. As such, later examples of the C.I began seating the observer (with gun) to the rear and the pilot forward, but still aft of the engine. This provided the pilot a better field of vision forwards and out of the cockpit while expanding the field of fire for the rear observer. This new arrangement produced the designation of "C.Ia".

In the end, the C.Ia performed admirably well throughout its frontline tenure, undertaking a host of reconnaissance sorties. The C.I series as a whole would be replaced by the improved C.II, which would sport an even more powerful engine, but this time showcasing the Benz brand as opposed to the Mercedes found in other Aviatik models.©MilitaryFactory.com
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.
Advertisements

Specifications



Service Year
1915

Origin
Imperial Germany national flag graphic
Imperial Germany

Status
RETIRED
Not in Service.
Crew
2

Production
500
UNITS


Automobil und Aviatikwerke - Imperial Germany
(View other Aviaton-Related Manufacturers)
National flag of Austria National flag of the Austro-Hungarian Empire National flag of the German Empire National flag of Hungary National flag of Romania National flag of Yugoslavia Austria-Hungary; German Empire; Romania; Yugoslavia
(OPERATORS list includes past, present, and future operators when applicable)
Intelligence-Surveillance-Reconnaissance (ISR), Scout
Surveil ground targets / target areas to assess environmental threat levels, enemy strength, or enemy movement.


Length
26.0 ft
(7.92 m)
Width/Span
41.0 ft
(12.50 m)
Height
9.7 ft
(2.95 m)
Empty Wgt
1,653 lb
(750 kg)
MTOW
2,954 lb
(1,340 kg)
Wgt Diff
+1,301 lb
(+590 kg)
(Showcased structural values pertain to the base Aviatik C.I production variant)
Installed: 1 x Mercedes D.II 6-cylinder inline engine developing 120 horsepower driving a two-bladed propeller unit at the nose.
Max Speed
88 mph
(142 kph | 77 kts)
Ceiling
11,483 ft
(3,500 m | 2 mi)
Range
261 mi
(420 km | 778 nm)
Rate-of-Climb
255 ft/min
(78 m/min)


♦ MACH Regime (Sonic)
Sub
Trans
Super
Hyper
HiHyper
ReEntry
RANGES (MPH) Subsonic: <614mph | Transonic: 614-921 | Supersonic: 921-3836 | Hypersonic: 3836-7673 | Hi-Hypersonic: 7673-19180 | Reentry: >19030


(Showcased performance specifications pertain to the base Aviatik C.I production variant. Performance specifications showcased above are subject to environmental factors as well as aircraft configuration. Estimates are made when Real Data not available. Compare this aircraft entry against any other in our database or View aircraft by powerplant type)
STANDARD:
1 x 7.92mm Parabellum machine gun in flexible mounting in rear cockpit.


Supported Types


Graphical image of an aircraft medium machine gun


(Not all ordnance types may be represented in the showcase above)
Hardpoint Mountings: 0


C.I - Base Production Model Series Designation; oberserver with trainable machine gun mounting placed in the front cockpit with pilot to the rear.
C.Ia - Observer with machine gun mounting moved to rear cockpit seating area with pilot moved to front.
C.II - More powerful Benz engine fitted to the series.


Military lapel ribbon for Operation Allied Force
Military lapel ribbon for the Arab-Israeli War
Military lapel ribbon for the Battle of Britain
Military lapel ribbon for the Battle of Midway
Military lapel ribbon for the Berlin Airlift
Military lapel ribbon for the Chaco War
Military lapel ribbon for the Cold War
Military lapel ribbon for the Cuban Missile Crisis
Military lapel ribbon for pioneering aircraft
Military lapel ribbon for the Falklands War
Military lapel ribbon for the French-Indochina War
Military lapel ribbon for the Golden Age of Flight
Military lapel ribbon for the 1991 Gulf War
Military lapel ribbon for the Indo-Pak Wars
Military lapel ribbon for the Iran-Iraq War
Military lapel ribbon for the Korean War
Military lapel ribbon for the 1982 Lebanon War
Military lapel ribbon for the Malayan Emergency
Military lapel ribbon representing modern aircraft
Military lapel ribbon for the attack on Pearl Harbor
Military lapel ribbon for the Six Day War
Military lapel ribbon for the Soviet-Afghan War
Military lapel ribbon for the Spanish Civil War
Military lapel ribbon for the Suez Crisis
Military lapel ribbon for the Ukranian-Russian War
Military lapel ribbon for the Vietnam War
Military lapel ribbon for Warsaw Pact of the Cold War-era
Military lapel ribbon for the WASP (WW2)
Military lapel ribbon for the World War 1
Military lapel ribbon for the World War 2
Military lapel ribbon for the Yom Kippur War
Military lapel ribbon for experimental x-plane aircraft


Ribbon graphics not necessarily indicative of actual historical campaign ribbons. Ribbons are clickable to their respective aerial campaigns / operations / aviation periods.

Images Gallery



1 / 1
Image of the Aviatik C.I
