Beech AT-10 Wichita


Twin-Engine Military Trainer Aircraft [ 1942 ]



Nearly 2,400 Beechcraft AT-10 Wichita aircraft were built from 1942 to 1944 for the United States Army Air Forces of World War 2.



Authored By: Staff Writer | Last Edited: 02/03/2017 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

GO TO SPECIFICATIONS [+]
Advertisements
The Beech Aircraft AT-10 "Wichita" was conceived by the company as a dedicated, low-cost twin-engine military trainer to meet a standing requirement by the United States Army Air Corps (USAAC) (to become the United States Army Air Forces - USAAF - in March of 1942). To facilitate mass production (and head-off a possible shortage of valuable aluminum during wartime), plywood was used throughout the construction of the airframe with metal only applied to the key sections such as the engine and cockpit area. The Wichita, beginning life as the company "Model 25", saw design from 1940 until 1941 and entered service in 1942. The AT-10 was named after the Kansan town of "Wichita" where the Beechcraft facility resided and 2,371 total examples followed with manufacturing handled by Beechcraft (1,771 units) and Globe Aircraft Corporation (600 units).

The original prototype was lost to an accident on May 5th, 1941 during testing by the USAAC and Beechcraft quickly turned around and constructed a second form as the "Model 26". Following the requisite evaluations, trials and certifications, the aircraft was adopted as the AT-10 and entered the USAAC inventory in February of 1942. Nearly 750 were on hand before the end of the year.

Dimensions of the Wichita included a length of 34.3 feet, a wingspan of 44 feet and a height of 10.3 feet. Empty was 4,750 lb with a Maximum Take-Off Weight (MTOW) nearing 6,130 lb. The Wichita was powered by a pair of Lycoming R-680-9 series air-cooled engines delivering 295 horsepower apiece. This propelled the aircraft to speeds of 198 miles per hour out to ranges of 770 miles and a service ceiling up to 16,900 feet.

The AT-10 proved crucial in the training of airmen intended for large aircraft as it stood as a stepping stone to operational-level bombers and transport types of equal or larger size. Production of the series was aided by its simplicity - the largely wooden approach allowed Beechcraft to outsource manufacture to wood-working / furniture plants to help meet demand. Even the all-important fuel stores were wooden with a synthetic rubber liner applied. The aircraft was in constant production until 1944 and the final examples emerged from Globe Aircraft lines (the company evolving to become Temco in the post-war period).

AT-10s operated until the end of the war which arrived in 1945.©MilitaryFactory.com
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.
Advertisements

Specifications



Service Year
1942

Origin
United States national flag graphic
United States

Crew
2

Production
2,371
UNITS


Beechcraft / Beech Aircraft / Globe Aircraft - USA
(View other Aviaton-Related Manufacturers)
National flag of the United States United States (retired)
(OPERATORS list includes past, present, and future operators when applicable)
Training (General)
Developed ability to be used as a dedicated trainer for student pilots (typically under the supervision of an instructor).


Length
34.3 ft
(10.46 m)
Width/Span
44.0 ft
(13.40 m)
Height
10.3 ft
(3.15 m)
Empty Wgt
4,751 lb
(2,155 kg)
MTOW
6,129 lb
(2,780 kg)
Wgt Diff
+1,378 lb
(+625 kg)
(Showcased structural values pertain to the base Beech AT-10 Wichita production variant)
Installed: 2 x Lycoming R-680-9 air-cooled radial piston engines developing 295 horsepower each.
Max Speed
199 mph
(320 kph | 173 kts)
Ceiling
16,896 ft
(5,150 m | 3 mi)
Range
771 mi
(1,240 km | 2,296 nm)


♦ MACH Regime (Sonic)
Sub
Trans
Super
Hyper
HiHyper
ReEntry
RANGES (MPH) Subsonic: <614mph | Transonic: 614-921 | Supersonic: 921-3836 | Hypersonic: 3836-7673 | Hi-Hypersonic: 7673-19180 | Reentry: >19030


(Showcased performance specifications pertain to the base Beech AT-10 Wichita production variant. Performance specifications showcased above are subject to environmental factors as well as aircraft configuration. Estimates are made when Real Data not available. Compare this aircraft entry against any other in our database or View aircraft by powerplant type)
None.


Supported Types




(Not all ordnance types may be represented in the showcase above)
Model 25 - Beechcraft product model; lost to accident
Model 26 - Subsequent Beechcraft product model
AT-10 - USAAF designation
