Sharps Model 1867 (Carbine)


Single-Shot, Breech-Loading Percussion Cap Carbine (1867)


Infantry Small Arms / The Warfighter

1 / 1
Right side view of the Sharps Model 1867 Carbine

Jump-to: Specifications

Over 100,000 Sharps carbines and rifles were produced from the period running 1850 to 1881.



Authored By: Staff Writer | Last Edited: 10/10/2017 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.
Christian Sharps initially spent time under the employ of other firearms manufacturers that included John Hall at the fabled Harpers Ferry. In 1851, Sharps took his developed trade down his own path and set up an arms manufacturing base - the Sharps Rifle Manufacturing Company of Hartford, Connecticut - entering into a business partnership with Robbins and Lawrence of Windsor, Vermont. Robbins and Lawrence gunsmiths manufactured the Sharps firearms and, in turn, Christian Sharps covered the technical aspects and marketing of his guns.

From there, Sharps delivered a bevy of breech-loading, heavy caliber, single-shot carbines that came into extensive play with the arrival of the American Civil War (1861 - 1865). His carbines proved very popular with both sides of the war and their popularity continued thereafter where they became favored arms of huntsmen and sporting types alike. The Model 1867 appeared only after the cessation of hostilities but some were believed issued to post-war Army personnel at the various military forts dotting the American landscape.
The Model 1867 was a single-shot weapon system featuring breech-loading. It was designed as a carbine to make for a shorter weapon than a standard rifle of the day. The Model 1867 was chambered for the.50 caliber metallic cartridge. The design of the Model 1867 was characterized by its mostly wooden receiver. The shoulder stock was integrated into the design, with the single wooden piece making up the hand grip and forend. The trigger was set within a teardrop-shaped ring under the hand grip and all major working components were housed in the area just above making up the receiver. The cocking hammer was set to the right side of the receiver and within reach of the trigger hand. The barrel was set within the forward portion of the receiver and banded to the furniture in a single place. The barrel protruded a short distance away from the wooden body and featured a simple forward post sight. The post was complemented by an open latter across the top of the receiver.

Specifications



Service Year
1867

Origin
United States national flag graphic
United States

Classification


Single-Shot, Breech-Loading Percussion Cap Carbine


Sharps - USA
National flag of the United States United States
(OPERATORS list includes past, present, and future operators when applicable)


Overall Length
1,200 mm
47.24 in
Barrel Length
546 mm
21.50 in
Empty Wgt
9.48 lb
4.30 kg
Sights


Open Ladder


Action


Single-Shot; Breech-Loading

(Material presented above is for historical and entertainment value and should not be construed as usable for hardware restoration, maintenance, or general operation - always consult official manufacturer sources for such information)


Caliber(s)*


.50; .50-70; .52-70

Rounds / Feed


Single Shot
Cartridge relative size chart
*May not represent an exhuastive list; calibers are model-specific dependent, always consult official manufacturer sources.
**Graphics not to actual size; not all cartridges may be represented visually; graphics intended for general reference only.
Max Eff.Range
1,500 ft
(457 m | 500 yd)
Rate-of-Fire
9
rds/min
Muzzle Velocity
1,200 ft/sec
(366 m/sec)


Model 1867 - Base Series Designation
