Ares Defense Shrike 5.56 Advanced Weapons System


Modular Weapons System (MWS) (2002)


Infantry Small Arms / The Warfighter

1 / 1
Image copyright www.MilitaryFactory.com; No Reproduction Permitted.

Jump-to: Specifications

The Ares Shrike 5.56 Advanced Weapon System can be configured to fulfill a variety of battlefield roles.



Authored By: Staff Writer | Last Edited: 10/03/2017 | Content ©www.MilitaryFactory.com; the following text is exclusive to this site.
Ares Defense of the United States produces the impressive Shrike 5.56 "Advanced Weapon System" (AWS). The Shrike 5.56 shares a high percentage of commonality in parts with the M16A4 model of the M16 family as well as its shorter carbine cousin - the M4A1 Carbine. From the outset, the weapon was designed by Geoffrey A. Herring to allow the operator in-the-field the firepower of the M249 SAW (Squad Assault Weapon) with the portability of the standard automatic assault rifle (the M16). The system can be converted to fire from the standard M16 30-round STANAG magazine, the 100-round Beat C-Mag ammunition drum or the M27 belt-link common to the M249 SAW (Squad Assault Weapon) in either 100- or 200-round "soft" and "hard" containers respectively. When fitted as such, the Shrike 5.56 is the lightest belt-fed machine gun in its class anywhere in the world - weighing in at a very manageable 7.5lbs fully-loaded. All this is made possible by the patented Ares Defense System, Incorporated "common receiver group".

The Shrike 5.56 comes in varying barrel lengths of 13, 16 and 20 inches with the 16-inch length being the standard option. The weapon is chambered for the 5.56x45mm NATO cartridge while the action is of a gas-operated piston (short-stroke tappet). Rate-of-fire is listed at between 625 and 1,000 rounds per minute while the barrel is air-cooled. The Shrike 5.56 can be set to semi-automatic and full-automatic fire as need be.

The original prototype (and proof-of-concept design) was known under the designation of EXP-1 while the improved form became the EXP-2. The EXP-1 was displayed to public sometime in 2000 and characterized by her revised M249 handguard as well as a Stoner 63-type quick-change barrel latch. The EXP-2 made use of the Picatinny rail handguard and incorporated more M16 parts to the firing action. The quick-change barrel was in line with that of the M60 GPMG. "Shrike 5.56 03A" was the designation used for the third-generation production models which sported slight improvements and revisions while being marketed as a more robust and reliable form.
The family of Ares Shrike 5.56 weapons includes the AAR (Ares Automatic Rifle). This variant features a telescopic stock with MIL-STD -1913 optics mount as well as a quick-change barrel. The AAR fires from the standard 30-round magazine as well as a 100-round drum.

The AAR/C is the "Ares Automatic Rifle Compact" and is differentiated from the AAR by its purposefully designed compact layout. This is made possible by its side-folding stock (fold along the right side of the receiver). Like the AAR, the AAR/C also makes use of a quick-change barrel function, the MIL-STD 1913 optics mount and can feed from the standard 30-round magazine or 100-round drum.

The ARES-16SPW (Ares Special Purpose Weapon) maintains aspects similar to that of the M16. In fact, all of the internal fire components and stocks are common to the family of rifles that is the M16, AR15 and the M4 Carbine. The major difference between this Ares product and the Colt/Armalite rifles and carbine is that the ARES-16SPW only fires from a belt feed. This belt feed is similar to that as found on the M249 SAW. Compared to that weapon, the ARES-16SPW offers the same level of firepower without the excessive weight.

The ARES-16 AMG (Assault Machine Gun (Dual Feed) allows fire from both the standard M16 4179 series STANAG magazines as well as the M27 disintegrating link belts common to the M249 SAW. There is no configuration required of the receiver for it accept either ammunition feed type. Magazines operate from the lower receiver while the linked-ammunition is inserted into a feed along the side of the receiver.

Optional accessories for any of these weapon systems includes a foregrip, varying scope optics and stocks, a bipod or tripod, carrying handle, underslung flashlight and underslung single-shot 40mm grenade launcher.

Development of the Shrike 5.56 has covered some seven years producing several patents. ARES Defense Systems, Incorporated is based out of Melbourne, Florida, USA.

Specifications



Service Year
2002

Origin
United States national flag graphic
United States

Classification


Modular Weapons System (MWS)


Ares Defense Systems, Incorporated - US
National flag of the United States United States
(OPERATORS list includes past, present, and future operators when applicable)
Automatic Function
Features a mechanical function to automate the firing action.
Fire Support
Capable of suppressing enemy elements at range through direct or in-direct fire.


Overall Length
711 mm
27.99 in
Barrel Length
330 mm
12.99 in
Empty Wgt
7.50 lb
3.40 kg
Sights


Optional Optics


Action


Gas-Operated Piston; Short-Stroke Tappet

Gas-Operated
Gas-operated system is featured, typically involving a gas cylinder and rear-driven piston directing energy to the bolt component.
(Material presented above is for historical and entertainment value and should not be construed as usable for hardware restoration, maintenance, or general operation - always consult official manufacturer sources for such information)


Caliber(s)*


5.56x45mm NATO

Sample Visuals**


Graphical image of a 5.56mm intermediate rifle cartridge
Rounds / Feed


30-round box; 100-round drum/pouch; 200-round box
Cartridge relative size chart
*May not represent an exhuastive list; calibers are model-specific dependent, always consult official manufacturer sources.
**Graphics not to actual size; not all cartridges may be represented visually; graphics intended for general reference only.
Rate-of-Fire
800
rds/min


EXP-1 - Initial Prototype; M249-style handguard.
EXP-2 - Improved Prototype; fitted with Picatinny rail system.
03A - Production Version
AAR (Ares Automatic Rifle) - telescoping stock; quick-change barrel; IL-STD 1913 optics mount; rail interface handguard; 30- and 100-round magazines; optional belt-feed module.
AAR/C (Ares Automatic Rifle Compact) - Quick-change barrel; side-folding stock; MIL-STD 1913 optics mount; rail interface handguard; 30- and 100-round magazines.
Ares-16SPW (Ares Special Purpose Weapon) - Internal fire components common to the AR15, M16 and M4 family; belt-feed fire only via M249 SAW linked ammunition; tripod adapter; carry, fixed or vehicle-mounted firing.
Ares-16 AMG (Assault Machine Gun (Dual Feed)) - Accepts both M16 4179 STANAG magazines as well as M27 disintegrating link ammunition.
