Novgorod

Circular Monitor Ironclad Warship [ 1874 ]

The Novgorod monitor ironclad utilized a rather unique circular design - only one was built and served with the Russians prior to World War 1.

Authored By: Staff Writer | Last Edited: 02/27/2020 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

Image from the Public Domain; showcasing the arrival of the Novgorod at Sevastopol around 1873.

VIEW SPECIFICATIONS [+]

The idea of a circular battleship emerged in a 1868 report from Scottish shipbuilder John Elder and evolved by the Royal Navy's Edward Reed but not officially realized until Rear-Admiral Andrei Popov of the Russian Navy pressed home the concept. The design revolved around a shallow-draft vessel capable of traversing low-level waters such as rivers and lakes, giving it proper access to more battlefronts than traditional well-armed warships could ever reach. The concept also spread out the displacement of both armor and armament, leading to a (theoretically) more powerful warship than possible through conventional designs. The end result, however, became one of the most panned warships ever completed - the "Novgorod" which was to represent a class of such ships. Its circular hull did allow for the expected armoring and armament benefits but it suffered from stability in anything more than calm waters and accuracy of its main armament was left wanting.

Only one example of this unique, and mostly forgettable, ship was built for the Russian Navy.

The Novgorod was intended as a new class of Russian monitors to help protect Black Sea and Dnieper River positions. She was named after the Russian city of Novgorod and constructed by the New Admiralty Shipyard of Saint Petersburg from the span of 1871 until 1874. Her keel was laid down on December 29th, 1871 and she was launched to sea on June 2nd, 1873. Completed in 1874 she began formal service with the Russian Navy.

Originally Novgorod was developed along the lines of a monitor ironclad. Her dimensions included a length of 101 feet with a beam equaling that while her draught was just 13.5 feet. Displacement was 2,500 tons (long) and power was from six compound-expansion steam engines fed by eight boilers - all this driving six shafts (the outboard pair were removed in 1876-1877 due to their minimal propulsion benefits). At best, the ship could hope to make upwards of 6.5 knots in ideal conditions.

Two smoke funnels - one at port side and the other starboard - were fitted along the sides of the circular shape with the main armament seated at direct center. The wheelhouse was fitted over the rear section of the circle (added between 1873 and 1874) and elevated walkways ("bridge wings") were featured as extensions from the funnel towers. A large-area superstructure (housing crew quarters) was added to the bow section and hand rails ran around nearly the entire diameter of the hull. Primary armament was 2 x 11" (280mm) guns though, while rifled, remained muzzle-loading weapons. A rotating turntable gave the guns their inherent traversal and could be aimed and fired jointly or independently of one another. Provisions were also made for carrying a "spar" torpedo weapon. Armor protection ranged from 9" at the belt to 9 inches at the barbette. The deck offered up to 2.75" of protection.

Novgorod's first, and only real, call-to-arms came during the Russo-Turkish War (1877-1878) where she was stationed at Odessa to act as a floating deterrent. Additional armament was added at about this time, this in the form of 2 x 4-pounder (3.4") cannon to improve her all-around defense - particularly against enemy torpedo boats which had grown to become a primary threat to capital ships. The war ended in March of 1878 with a Russian-Coalition victory.

In the post-war period, armor was added to her engine area and the main gun battery. In 1892 she was redesignated a "coastal defense ironclad" and had 2 x 37mm cannons added. From then on she made a few cruises in good weather periods but eventually deteriorated to the point that her services were no longer needed. She was struck from the Naval Register in July 1903 and sold for scrapping before the end of 1911.

Thus ended the idea of a circular metal-clad warship.©MilitaryFactory.com

Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.

Specifications

Service Year

1874

Origin

Russia

Status

DECOMMISSIONED
Destroyed, Scrapped.

Complement

151
PERSONNEL

Class

Novgorod-class

Number-in-Class

1
VESSELS

Ships-in-Class

Novgorod

Imperial Russia

(OPERATORS list includes past, present, and future operators when applicable)

✓ Offshore Operation
Activities conducted near shorelines in support of allied activities.

Length

101.0 ft
30.78 m

Beam

101.0 ft
30.78 m

Draught

13.5 ft
4.11 m

Displacement

2,500
tons

Installed Power: 8 x Cylindrical boilers feeding 6 x Compound-Expansion steam engines driving 6 x Shafts.

Surface Speed

6.5 kts
(7.5 mph)

Range

478 nm
(550 mi | 885 km)

ORIGINAL:

2 x 11" (280mm) muzzle-loaded rifled main guns

1877:

2 x 11" (280mm) muzzle-loaded rifled main guns

2 x 4-pounder (3.4-inch / 86mm) secondary guns

1892:

2 x 11" (280mm) muzzle-loaded rifled main guns

2 x 4-pounder (3.4-inch / 86mm) secondary guns

2 x 37mm (1.5-inch) Hotchkiss five-barreled revolving cannons.
