Landing Ship, Tank Mk II (LST2)


Amphibious Assault Transport Vessel [ 1942 ]



LST vessels proved critical to Allied amphibious operations dotting the World War 2 battlescape.



Authored By: Staff Writer | Last Edited: 06/07/2016 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

VIEW SPECIFICATIONS [+]
Even before the massive amphibious operations dotting the World War 2 battlescape came to pass and prior to the American entry into the conflict proper, thought was already being given by Allied warplanners to the development of large ocean-going assault ships capable of moving man, machine, and supplies from offshore staging points to unprepared beaches. There were various types of these vessels eventually created for warfare - dedicated troop ships, tank transports and the like - and a myriad of variants appeared in-between. The British made steady progress in the field and eventually produced the "Landing Ship, Tank Mk I" (LST(1)) series based on its experiences at Dunkirk in 1940 - the purpose to bring armor to within reach of the beach line and help carry the fight directly to the enemy where they waited. Three Mk I series ships were completed before attention then turned to the definitive assault ship of the war - "Landing Ship, Tank Mk II" (LST(2)).

Understanding the importance of large-scale production in bringing these ships to pass, a British attache was sent to the United States to secure manufacture of the new class. With the details ironed out from late-1941 to early-1942, an order for the ships was placed during February of 1942.

Unlike the original LST(1) vessels - which were simply modifications of existing oil tankers, useful because of their ocean-going capabilities and shallow draughts - the LST(2) was a purpose-designed warship and, therefore, given creative freedom in its eventual make-up. The relatively compact twin-diesel engine arrangement sat at the rear of the hull and under the tank cargo deck (the Third Deck of four total) resulting in full use of the boat's length for cargo management and storage. Dimensions were more contained than in the previous offering, improving water-handling and speeds, while the shallow draught design was continued. Doors were set at the bow and hinged to open outwards from centerline. Within the bow was the loading ramp to facilitate the crossing of vehicles from ship to water. The lower deck was sectioned off for tanks of medium and light class weight while the upper deck (Second Deck) was devised to support lighter-weight vehicles. Beyond this, the ships could also support 150 men and their related supplies. Berthing for the troops was along the edges of the Second Deck.©MilitaryFactory.com
As completed, the LST(2) weighed 3,800 long tons under full load and showcased a length of 328 feet, a beam of 50 feet, and a draught of 14 feet (8 feet at the bow). The ramp provided some run-off into the tide until 1943 when floating pontoon sections were used to aid vehicles coming off the ship (creating a "ship-to-shore causeway" of sorts). The General Motors 12-567 diesel engines outputted 1,800 horsepower (each) and drove two shafts under stern at speeds up to 12 knots. Internally, the cargo hold held space for eighteen tanks (30-ton class) or thirty military trucks. For self-defense the ship was outfitted with 1 x 76mm Dual-Purpose (DP) gun, 6 x 40mm Bofors Anti-Aircraft (AA) guns, 6 x 20mm Oerlikon AA guns, 2 x 0.50 caliber Heavy Machine Guns (HMGs), and 4 x .30 caliber machine guns.

The LST(2) production effort was part of the larger naval construction initiative pushed by the American congress in the early war years and the first keel of the series was laid on June 10th, 1942 at Newport News, Virginia. Twenty-three ships were readied before the end of the year. Such was the need for LSTs that production vehicles were being constructed even before a prototype had been completed and tested. Since the draught of the LST(2) was shallow, the ships could be built inland away from already-committed coastal shipyards of the United States.

In the end, 1,051 LST ships were built between 1942 and 1945 and 113 of these were passed to Britain via Lend-Lease while a further 101 were cancelled as the war progressed. The ships proved so critical to Allied actions that their priority never waned during the course of the war. A vessel could be completed in under two months and modifications were accordingly added to the series as war time use showcased the need in streamlining the ship-to-shore process. For their part in the war, the large movers proved themselves strong, reliable, and robust with only a few lost to enemy action (26 officially noted). They were nicknamed "Large Slow Target" ("LST") by some. Operators included both Britain and the United States as well as Canada.

LST(2) ships were used in every theater that the Allies fought in and saw post-war use for a time - including action in the Korean War (1950-1953) that followed. By this time, the revised design was capable of reaching speeds over 17 knots.©MilitaryFactory.com
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.

Specifications



Canada; United Kingdom; United States
Operators National flag of Canada National flag of the United Kingdom National flag of the United States
1942
Commissioned
United States
National Origin
265
Complement
LST2-class
Hull Class
1,051
Number-in-Class
Over 1,000 vessels completed to the LST(2) standard from 1942 to 1945 carrying the LST designation.
Ships-in-Class


Amphibious Assault
A shallow draught, and other qualities, give this vessel the ability to support amphibious assault operations close-to-shore.


327.8 feet
(99.91 meters)
Length
50.0 feet
(15.24 meters)
Beam
14.0 feet
(4.27 meters)
Draught
4,000
tons
Displacement


2 x General Motors 12-567 diesel engines developing 1,800 horsepower to 2 x shafts.
Propulsion
12.0 knots
(13.8 mph)
Surface Speed
23,758 nm
(27,340 miles | 43,999 km)
Range
1 knot = 1.15 mph; 1 nm = 1.15 mile; 1 nm = 1.85 km


1 x 3" (76mm) Dual-Purpose deck gun
6 x 40mm Bofors Anti-Aircraft (AA) guns
6 x 20mm Oerlikon AA guns
2 x 0.50 caliber Browning heavy machine guns
4 x 0.30 caliber Browning medium machine guns


None.


Military lapel ribbon for the Cold War period
Military lapel ribbon for early warship designs
Military lapel ribbon for the Falklands War
Military lapel ribbon for the 1991 Gulf War
Military lapel ribbon for the Korean War
Military lapel ribbon representing modern aircraft
Military lapel ribbon for the Attack on Pearl Harbor
Military lapel ribbon for the Russian Invasion of Ukraine
Military lapel ribbon for the Vietnam War
Military lapel ribbon for the World War 1
Military lapel ribbon for the World War 2

Images



1 / 12
Image of the Landing Ship, Tank Mk II (LST2)
