Koni-class (Project 1159)

Anti-Submarine Warfare (ASW) Frigate [ 1975 ]

The Koni-class built by the Soviet Union served primarily in export to allies with fourteen of the type being built into 1988.

Authored By: Staff Writer | Last Edited: 01/26/2018 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

VIEW SPECIFICATIONS [+]

Frigate warships have been a mainstay of modern navies for centuries and evolved to become multi-mission, highly-capable fighting forms today. During the Cold War decades (1947-1991), the Soviet Union designed and developed a new frigate warship for the purpose of Anti-Submarine Warfare (ASW) operations and this became the fourteen-strong Koni-class. The type was built during the period spanning 1975 to 1988 and went on to see service as largely an export product with the navies of Algeria, Bulgaria, Cuba, East Germany, Egypt, Libya, and Yugoslavia. The Koni-class was ordered as a replacement for the outgoing Riga-class series of frigates which numbered sixty-eight in all and served largely the same operators though with origins set in the 1950s.

The vessel displaced at 1,140 tons under standard load and up to 1,900 tons under full load. Overall length was 95 meters with a beam of 12.7 meters and a draught of 4.2 meters. Power was served through 2 x diesel units coupled to a single gas turbine arranged in a CODAG scheme (COmbined Diesel And Gas) which allowed for short bursts of straightline speed when the gas turbine was engaged alongside the diesels. The vessel could make headway at up to 27 knots with ranges out to 3,300 kilometers. Output was 35,000 horsepower to 3 x shafts underneath.

The profile was highly conventional with a up-swept bow and low stern section. The bridge and its corresponding superstructure were well-forward of midships. The main mast (enclosed) sat at the rear of this structure and various other protrusions were identified down the line from the bridge to the stern. A pair of large primary turrets were featured - one over the bow and the other over the stern. The smoke funnel was well-buried within the design, attached as an aft section of the bridge superstructure. The total crew complement numbered 110 personnel made up of officers and sailors.©MilitaryFactory.com

Onboard systems comprised of various processors, suites, trackers, directors and engagement units. Sonar was also an appropriate part of the base design. Armament included an SA-N-4 "Gecko" surface-to-air missile series launcher as well as 4 x SS-N-2C Anti-Ship Missile (ASM) launchers. There were 4 x 76.2mm Dual-Purpose (DP) guns set within the two aforementioned turrets and 4 x 30mm guns. The warship was also outfitted with 2 x RBU-6000 series depth charge launchers and held provision for carrying up to twenty naval mines for dispersal in contested seas.

The Koni-class was the NATO reporting name while the group came to be known in the Soviet inventory as "Project 1159". Three distinct construction batches emerged which was led by the Project 1159 "Koni I" series ships made for the nations of Bulgaria, East Germany and Yugoslavia. Then followed Project 1159T "Koni II" which included ships for Algeria and Cuba and Project 1159TR "Koni II" were warships delivered to Libya. The primary difference between the Koni I and Koni II series ships was that the former vessels were designed particularly for European water operation and the latter vessels intended for warm water environments like those found in the Middle East region. There might have been some slight differences in design between the ship groups and countries operating them - leading to some variation on overall dimensions and armament fits.

The Soviet Navy made use of one Koni-class warship (the Delfin) for a time but this was reserved for the training of foreign parties in the details of the new type. The sole example was eventually delivered to Bulgaria during 1990 as the "Brave". Some Koni-class ships continue in service today (2015) but many first-rate navies have decommissioned and scrapped their stocks.©MilitaryFactory.com

Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.

Specifications

Service Year

1975

Origin

Soviet Union

Complement

110
PERSONNEL

Class

koni-class

Number-in-Class

14
VESSELS

Ships-in-Class

Delfin (Koni I); Nerpa (Koni I); Krechet (Koni I); Sokol (Koni I); SKR-481 (Koni I); SKR-149 (Koni I); SKR-482 (Koni II); SKR-28 (Koni II); SKR-35 (Koni II); SKR-471 (Koni II); SKR-129 (Koni II); SKR-451 (Koni II); SKR-201 (Koni II); SKR-195 (Koni II)

Algeria; Bulgaria; Cuba; East Germany; Libya; Soviet Union; Yugoslavia

(OPERATORS list includes past, present, and future operators when applicable)

✓ Offshore Bombardment
Offshore bombardment / attack of surface targets / areas primarily through onboard ballistic weaponry.

✓ Land-Attack
Offshore strike of surface targets primarily through onboard missile / rocket weaponry.

✓ Maritime Patrol
Active patroling of vital waterways and maritime areas; can also serve as local deterrence against airborne and seaborne threats.

✓ Airspace Denial / Deterrence
Neutralization or deterrence of airborne elements through onboard ballistic of missile weaponry.

✓ Fleet Support
Serving in support (either firepower or material) of the main surface fleet in Blue Water environments.

Length

311.5 ft
94.95 m

Beam

42.0 ft
12.80 m

Draught

13.8 ft
4.20 m

Displacement

1,140
tons

Installed Power: 2 x Diesel units with 1 x Gas turbine in CODAG arrangement developing 35,000 horsepower to 3 x shafts.

Surface Speed

27.0 kts
(31.1 mph)

Range

1,781 nm
(2,050 mi | 3,299 km)

1 x SA-N-4 "Gecko" Surface-to-Air Missile (SAM) launcher

4 x SS-N-2C "Styx" Anti-Ship (AS) missile launchers

4 x 76.2mm Dual-Purpose deck guns

4 x 30mm autocannons

2 x RBU-6000 depth charge launchers

20 x Naval mines (optional)

Supported Types

Graphical image of a modern warship turreted deck gun armament

Graphical image of an air-to-air missile weapon

Graphical image of an aircraft anti-ship missile

(Not all weapon types may be represented in the showcase above)

None.

Military lapel ribbon for the Cold War period

Military lapel ribbon for early warship designs

Military lapel ribbon for the Falklands War

Military lapel ribbon for the 1991 Gulf War

Military lapel ribbon for the Korean War

Military lapel ribbon representing modern aircraft

Military lapel ribbon for the Attack on Pearl Harbor

Military lapel ribbon for the Russian Invasion of Ukraine

Military lapel ribbon for the Vietnam War

Military lapel ribbon for the World War 1

Military lapel ribbon for the World War 2

Ribbon graphics not necessarily indicative of actual historical campaign ribbons. Ribbons are clickable to their respective naval campaigns / operations / periods.

Images Gallery

1 / 2

Image from the Public Domain.

2 / 2

Image from the Public Domain.

❮ ❯
