Infantry Tank Mk IV Churchill (A22)


Infantry Tank [ 1941 ]



Undoubtedly, the Churchill Infantry Tank proved to be the most important British tank of World War 2 and was produced in the thousands.



Authored By: Staff Writer | Last Edited: 10/17/2018 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

VIEW SPECIFICATIONS [+]
The Churchill served the British Army and allied forces as the most important of its type during World War 2 (1939-1945), rivaling even the famous American M4 Sherman and fabled Soviet T-34 medium tanks of the conflict. Such was its value that the chassis served as the basis for a slew of variants to follow, both direct-combat and non-combat forms, that made it one of the more classic tanks ever adopted despite its appearance akin to a World War 1 (1914-1918) steel beast. Only the Infantry Tank Valentine was produced in more numbers than the Churchill though none could match the Churchill's multi-role capabilities that helped it to see an extended service life in the post-war years.

By this point in its military history, the British Army had adopted a doctrine centered around use of light, fast "Cruiser Tanks" coupled with slow, better-armed-and-armored "Infantry Tanks". Infantry Tanks would be used to smash enemy defensives to which Cruiser Tanks would then be sent in to exploit enemy flanks. The classic Churchill tank belonged to the Infantry Tank way-of-thinking in this arrangement, hence its large dimensions, overall weight and very capable turret armament.

The request for a new Infantry Tank came through specification "A20" appearing September 1939, a time when the British Empire was under increasingly direct threat from invasion from Axis forces. The initial approach was for a heavy battlefield tank designed for the concept of trench warfare seen in the bloody fighting of World War 1 and a large shape was adopted to break any possible stalemate across a given battlefield. However, early evaluation of the design approach quickly showed such a vehicle's inherent limitations - particularly where the German fast-moving battlefield concepts were concerned. As such, the decision was made to flesh out a more lightweight offering and this came under the specification of "A22". Vauxhall Motors was charged with its design and development to which originated the classic "Churchill" tank, formally recognized under the long-form name of "Infantry Tank Mk IV".

Due to time constraints and the ever-evolving war across the Channel, Vauxhall worked from a pressed schedule which forced the vehicle into army hands as quickly as possible. This sort of haste then allowed real world use to showcase the design's mechanical unreliability which led to a quick revision. Some 1,000 tanks were eventually affected by this production push and only the later revisions saved the line form complete failure.

Initial Churchill marks were outfitted with the 2-pounder main gun, a relatively small 40mm caliber weapon found across both the Churchill Mk I and Mk II. Mk Is also featured a 3" howitzer fitted to the front of the hull as well as a coaxial 7.92mm Besa machine gun - the 3" gun was given up in the Mk II. The following Churchill Mk III and Mk IV were fitted with a serviceable 57mm main gun while the Mk VI and Mk VII were given more appropriate armament in the 75mm main gun. Other forms then followed and carried various caliber armament including 95mm howitzer flavors intended as "close support" fighting platforms. The definitive production model became the aforementioned Mk IV with 1,622 produced and this was followed, in numbers, by the Mk VII (A22F) with 1,600 examples and then the Mk II seeing 1,127 units produced.

Initial actions of Churchills were rather unspectacular, particularly during the Dieppe landings of 1942 where many failed to reach the shore and those on shore were pinned and doomed to fail. The raid was a concerted effort to retake the vital French port of Dieppe through a 6,000-strong infantry force backed by armor coming ashore by way of a brazen amphibious landing operation. However, the large vehicles required landing craft for the assault and then additional engineering support to even cross the beach. The German defenses held the upper hand and the Dieppe Raid was a complete failure for the Allies. Much of the decimated force was made up of Canadians.©MilitaryFactory.com
It was in the fighting across North Africa that Churchills began to showcase their worth, providing much needed protection through their thick armor and strong firepower through their now 6-pdr main guns. They operated alongside infantry formations as well as other tank elements and cross-country capabilities proved sound. If the large tank suffered one noticeable limitation it was in its overall speed which made it hard to keep up with faster mechanized formations. Many improvements were also being made as battlefield experience allowed including riveted and hybrid construction of the original cast turret designs. Other improvements were added to help "tropicalize" the tank in the desert fighting. Additional armor was also eventually added and in-the-field fixes saw extra track sections, wheels, sandbags and lumber used to further bolster protection.

Churchills played a crucial role in the October 1942 "Second Battle of El Alamein" which claimed a decisive (and much-needed) Allied victory. One action involving a Churchill tank led to the capture of the new German "Tiger I" heavy tank, allowing Allied warplanners a complete example from which to learn its strengths and weaknesses.

The tank was then pressed into further service during the Italian campaign in the march to Rome and made up a major component of the British and Commonwealth armor push northwards. Throughout northern France, Churchills were also used during the June 1944 "D-Day" landings at Normandy ,which proved critical to Allied success in Europe, and beyond. Through Lend-Lease, the Soviet Army was also able to utilize British Churchills during its actions near Kursk, though this resulted in a German tactical victory. Churchills did not see combat service in the Pacific Theater but did go on to earn more combat experience during the Korean War (1950-1953). These actions marked the end of British support for its Churchills as world-wide armor doctrine now focused on the "Main Battle Tank" concept.

The Churchill served in many non-direct combat forms which helped to solidify its place in armored warfare history. Variants included dedicated engineering versions, bridgelayers, charge-layers, mine clearance vehicles (flails), flame tanks and converted Armored Personnel Carriers (APCs) under the "Kangaroo" name - Churchill offshoots ranged from the purposeful to the odd.

Despite its bygone appearance, the Churchill proved highly valued in the fighting of World War 2, helping to bring about complete Allied victory and an end to the war in Europe. Churchill tanks served the British from 1941 to 1952 with 7,368 produced of all marks and variants. Operators included (beyond the British) Australia, Canada, Iraq (Kingdom of), Ireland, Poland and the Soviet Union (via Lend-Lease). Irish Churchills were not retired until 1969 and the arrival of wartime Cruiser Tank Comets. Australia, Canada and Iraq all replaced their Churchills with Centurion Main Battle Tanks and Soviet Churchills were replaced by incoming stocks of Josef Stalin IS-3 and IS-10 series heavy tanks.

Churchill tanks were manufactured by Vauxhall Motors, Woolwich Arsenal and Harland and Wolff of the U.K.©MilitaryFactory.com
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.

Specifications



Service Year
1941

Origin
United Kingdom national flag graphic
United Kingdom

Crew
5
CREWMEN
Production
7,368
UNITS


Vauxhall Motors / Woolwich Arsenal / Harland & Wolff - UK
(View other Vehicle-Related Manufacturers)
National flag of Australia National flag of Canada National flag of Ireland National flag of Poland National flag of the Soviet Union National flag of the United Kingdom Australia; Canada; Ireland; Poland; United Kingdom; Soviet Union
(OPERATORS list includes past, present, and future operators when applicable)
Engineering
Onboard systems provide solutions to accomplish a variety of battlefield engineering tasks.
Infantry Support
Support allied ground forces through weapons, inherent capabilities, and / or onboard systems.
Medium Tank
Design providing enhanced armor protection and firepower over that of lightweight offerings - but lacking the general capabilities of heavier solutions.
Tank-vs-Tank
Engage armored vehicles of similar form and function.
Utility
General utility-minded design to accomplish a variety of battlefield tasks, typically in a non-direct-combat fashion.
Special Purpose
Special purpose design developed to accomplish an equally-special battlefield role or roles.


Length
24.3 ft
7.4 m
Width
10.7 ft
3.25 m
Height
8.2 ft
2.5 m
Weight
89,596 lb
40,640 kg
Tonnage
44.8 tons
MEDIUM
(Showcased structural values pertain to the Churchill Mk VII production variant. Length typically includes main gun in forward position if applicable to the design)
Powerplant: 1 x Bedford Twin-Six gasoline engine developing 350 horsepower.
Speed
14.9 mph
(24.0 kph)
Range
55.9 mi
(90.0 km)
(Showcased performance specifications pertain to the Churchill Mk VII production variant. Compare this entry against any other in our database)
Early:
1 x QF 2-pounder (40mm) main gun OR 1 x 6-pdr (57mm) main gun.
1 x 3" Howitzer in hull (later removed)
1 x 7.92mm Besa coaxial machine gun

Late:
1 x 75mm main gun
1 x 7.92mm Besa coaxial machine gun
1 x 7.92mm Besa bow-mounted machine gun

Alternative:
1 x 95mm Howitzer


Supported Types


Graphical image of a tank cannon armament
Graphical image of a tank medium machine gun


(Not all weapon types may be represented in the showcase above)
150 x 40mm projectiles OR 84 x 57mm projectiles OR 84 x 75mm projectiles OR 47 x 95mm projectiles.
4,950 - 9,450 x 7.92mm ammunition


Churchill I - Armed with 2-pounder main gun with hull-mounted 3" howitzer; Besa coaxial machine gun; 303 examples.
Churchill Mk II ("Churchill Ia") - Hull-mounted machine gun replacing 3" howitzer; 1,127 examples.
Churchill Mk IICS ("Churchill II") - Close-Support version with turret howitzer and 2-pdr gun in hull.
Churchill Mk III - Sans hull howitzer; 6-pdr main gun; welded turret construction; 675 examples.
Churchill Mk IV - Quantitative definitive Churchill mark; based on Mk III model; cast turret construction; 6-pdr main guns; 1,622 examples.
Churchill Mk V - Close-Support version with 95mm howitzer in turret; cast turret; 241 examples.
Churchill Mk VI - Revised turret collar; fitted with 75mm Mk V main gun; 200 examples.
Churchill Mk VII (A22F/A42/"Heavy Churchill") - 75mm main gun; additional armor protection; 1,600 examples.
Churchill Mk VIII - 95mm howitzer in turret; revised turret design.
Churchill Mk IX (LT = "Light Turret") - Churchill VII model turret with 6-pdr main gun; additional armor; revised transmission and suspension system.
Churchill Mk X - Churchill IX additions to Churchill Mk VI models
Churchill Mk XI - Churchill Mk VIII turret; additional armor protection
Churchill NA75 - North African Campaign version; Churchill Mk IV models with 75mm M4 Sherman tank guns; cast turret; 200 examples.
Churchill Oke - Churchill Mk II or Mk III flamethrower tanks
Churchill AVRE ("Armoured Vehicle Royal Engineers") - Armored Engineering Vehicle
Churchill ARV - Armored Recovery Vehicle
Churchill ARK - Bridgelayer; 65 foot span
Churchill Crocodile - Flame Tank
Gun Carrier, 3in, Mk I, Churchill (A22D) - Prototype Vehicle fitted with 3" anti-aircraft gun
Churchill Flail / Toad (FV3902) - Mine Clearing Vehicle
Churchill Goat - Charge-Layer
Churchill Great Eastern - Bridgelayer; 60 foot span
Churchill Kangaroo - Converted Armored Personnel Carriers (APCs)
Tank, Infantry, Black Prince (A43) - Proposed Heavy Tank variant of 1945; six prototypes; cancelled.


Military lapel ribbon for the American Civil War
Military lapel ribbon for pioneering aircraft
Military lapel ribbon for the Arab-Israeli War
Military lapel ribbon for the Battle of the Bulge
Military lapel ribbon for the Battle of Kursk
Military lapel ribbon for the Cold War
Military lapel ribbon for the Falklands War
Military lapel ribbon for the Indo-Pak Wars
Military lapel ribbon for the Korean War
Military lapel ribbon for the 1991 Gulf War
Military lapel ribbon representing modern aircraft
Military lapel ribbon for the Soviet-Afghan War
Military lapel ribbon for the Spanish Civil War
Military lapel ribbon for the Ukranian-Russian War
Military lapel ribbon for the Vietnam War
Military lapel ribbon for the World War 1
Military lapel ribbon for the World War 2
Military lapel ribbon for the Yom Kippur War
Military lapel ribbon for experimental military vehicles


Ribbon graphics not necessarily indicative of actual historical campaign ribbons. Ribbons are clickable to their respective campaigns / operations.

Images Gallery



1 / 7
Image of the Infantry Tank Mk IV Churchill (A22)
