Morris Light Reconnaissance Car (LRC)


Fast Armored Car [ 1940 ]



The Morris Light Reconnaissance Car was developed as a Home Defence vehicle but saw considerable service overseas during the fighting of World War 2.



Authored By: Staff Writer | Last Edited: 12/17/2018 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

GO TO SPECIFICATIONS [+]
Advertisements
Light reconnaissance vehicles were crucial to battlefield success in the World War 2 period (1939-1945). To fulfill this requirement, all major fighting participants of the conflict utilized some form of vehicle for the role. For the British, the Morris Light Reconnaissance Car (LRC) became just one of several fielded - but this type was hastily developed during 1940 as a Homeland Defence instrument to help shore up losses of armor in the desperate British departure from France back in May of that year (during the famous "Miracle of Dunkirk").

Even as British industry worked to develop long-term solutions for the military, local, smaller firms were pushed by the government to come up with cheaper, viable products to help defend the British mainland from enemy invasion - which was a very real threat following the fall of France, Norway, Belgium and the rest of the Low Countries. Morris Motors Ltd drew up plans for what became the Morris LRC in short order, relying on existing, off-the-shelf components as a cost-effective measure to bring the crude compact vehicle about.

A basic four-wheeled chassis was at the heart of the car's arrangement though the engine (an in-house Morris 4-yclinder gasoline unit of 72 horsepower output) was relocated to the rear and a crew compartment set at the front-middle. Interestingly, all three crewmen were seated shoulder-to-shoulder across the beam of the car - this to add to the already-cramped operating conditions of the lightly armored hull superstructure - with the driver positioned at center. Hinged doors along the sides of the hull offered basic entry-exit and hatches gave access to the armament fit over the hull.

Primary armament fitted was the 0.55in Boys Anti-Tank Rifle (ATR) set in an emplacement over the left of the hull roof while a 0.303 caliber BREN Light Machine Gun (LMG) was installed in a turret over the right of the hull roof. This provided the vehicle with a relatively effective arrangement against lightly-armored enemy vehicles as well as infantry. The ATR was installed over the radioman's position and operated by the left-hand-side crewmember. Double hatches gave access to the heavy rifle which could be positioned to fire forwards or backwards depending on the situation.

The initial Mark I production model had only rear-wheel drive power, limiting its tactical usefulness to an extent, and the Mark I OP offshoot was a developed "Observation Post" model sans its turret but fielding a pair of rangefinders. The Mark II rectified the drive limitation of the Mk I by introducing four-wheel drive capability. Beyond this, the line existed in several notable, yet unfulfilled, prototypes that included the Morris Experimental Tank (fitting two complete turrets), the "Firefly" (the bow had a 6-pdr field gun), the "Salamander" (two-seat model with single roof-mounted turret), and the "Glanville Fighter Car" (single-seat model with two machine guns in fixed mountings). None of the prototypes were evolved into operational forms.

The Morris LRC was utilized by British forces where it was needed - in Tunisia of the North African Campaign, along the West Front of Europe, and in the Middle East Theater. Polish forces were also handed the type. Total production of the series reached over 2,200 in all.©MilitaryFactory.com
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.
Advertisements

Specifications



Service Year
1940

Origin
United Kingdom national flag graphic
United Kingdom

Crew
3
CREWMEN
Production
2,200
UNITS


National flag of Malaysia National flag of Poland National flag of the United Kingdom Malaysia; Poland; United Kingdom
(OPERATORS list includes past, present, and future operators when applicable)
Armored Car
Design, of typically lightweight nature, providing onroad/offroad capabilities for the scouting or general security roles.
Reconaissance
Can conduct reconnaissance / scout missions to assess threat levels, enemy strength, et al - typically through lightweight design.


Length
13.3 ft
4.05 m
Width
6.7 ft
2.05 m
Height
6.2 ft
1.88 m
Weight
8,157 lb
3,700 kg
Tonnage
4.1 tons
LIGHT
(Showcased structural values pertain to the base Morris Light Reconnaissance Car (LRC) production variant. Length typically includes main gun in forward position if applicable to the design)
Powerplant: 1 x Morris 4-cylinder gasoline-fueled engine developing 72 horsepower.
Speed
49.7 mph
(80.0 kph)
Range
239.2 mi
(385.0 km)
(Showcased performance specifications pertain to the base Morris Light Reconnaissance Car (LRC) production variant. Compare this entry against any other in our database)
1 x 0.55" Boys Anti-Tank Rifle (ATR) in left-side hull roof emplacement.
1 x 0.303 caliber BREN Light Machine Gun in right-side hull roof turret.


Supported Types


Graphical image of a tank anti-tank guided missile
Graphical image of a tank medium machine gun


(Not all weapon types may be represented in the showcase above)
Not Available.


Morris Light Reconnaissance Car - Base Series Name.
Mark I
Mark I OP
Mark II
