Lohner B.VII


Reconnaissance Fighter / Light Bomber [ 1915 ]



The Lohner B.VII was the unarmed version of the Lohner reconnaissance planes that included the armed C.I.



Authored By: Staff Writer | Last Edited: 04/11/2016 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

GO TO SPECIFICATIONS [+]
Advertisements
The Lohner B.VII was a two-seat reconnaissance aircraft produced by and for the Austro-Hungarian Empire during World War 1. While a pre-war military design at its core, the B.VII became the definitive combat-worthy form of the series and was utilized for a time beginning in August of 1915. From there, the aircraft was revised into a more powerful (and ultimately armed) form as the Lohner C.I. These two Lohner designs exhibited healthy operating ranges but were eventually outclassed by the latest crop of fighters entering the airstream by 1917.

Design of the original Lohner B.I series began before the hostilities of World War 1 broke out across Europe, this by the Jakob Lohner AG firm. The B.I was an unarmed reconnaissance platform with seating for two, swept-back biplane wings and a 90 horsepower Austro-Daimler engine. Not wholly satisfied with the performance of the B.I, Jakob Lohner and his team devised successfully progressive and more powerful forms of the B.I that became the B.II, B.III, B.IV, B.V and ultimately the B.VI. It was not under the development of the definitive B.VII that this Lohner aircraft series finally came into its own.

The Lohner B.VII took on a distinct planform. Like those Lohner designs before it, the B.VII featured swept back biplane wings with double bays and parallel struts. These were staggered and fitted above and ahead of the pilot with the lower wing assembly showcasing dihedral (upward angle). The large liquid-cooled engine obstructed some of the forward view and powered a two-blade propeller. The observer/gunner sat in the separated rear portion of the open air cockpit (the two personnel were seated in tandem) and was the trained lookout doubling as a machine gunner if the aircraft was armed as such. The fuselage, with its straight-faced sides, tapered off into a conventional empennage with large-area horizontal planes (also featuring sweep back) and a single vertical tail fin. The undercarriage was traditional of the times and fitted two main landing gear wheels on braced struts along the forward underside of the fuselage coupled with a simple tail skid at the extreme aft-end of the tail. Interestingly, the Lohner aircraft could sport an internal bomb payload of up to 180lbs.

Lohner produced two versions of this reconnaissance plane - the B.VII and the C.I. The B.VII was the (generally) unarmed model and fitted with either a 150- or 160-horsepower Austro-Daimler engine to which 73 of the type were produced (while categorized as unarmed, some B.VIIs did fit a trainable machine gun in the rear cockpit). The C.I represented the "official" armed version, this fitting a single machine gun on a flexible mounting in the rear cockpit for the observer/gunner. The C.I was assigned an Austro-Daimler 6-cylinder inline liquid-cooled engine of 160 horsepower under an engine cowling (the B.VII showcased an exposed engine and no engine cowl) and built to the tune of some 40 examples.

The B.VII sported a wingspan of 50 feet, 6 inches. Endurance was a reported 6 hours in the air while a rate-of-climb of 350 feet-per-minute was possible. The B.VII entered service in 1915. As the B.VII showcased generally excellent endurance for an aircraft of the Great War, this translated to fine long-range service and proving adept at scanning the fronts across Italy. Its bombload did involve the aircraft in occasional strike missions as needed, against both ground-based structures and naval vessels in the region. The armed C.I entered into service with the Austro-Hungarian Empire a short time later in 1916.

By 1917, both Lohner reconnaissance types were removed from frontline service and had their production lines reassessed. All aircraft were produced by Lohner (some C.Is were also manufactured by Ufag) in Austria-Hungary for the Imperial and Royal Aviation Troops.©MilitaryFactory.com
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.
Advertisements

Specifications



Service Year
1915

Origin
Austria-Hungary national flag graphic
Austria-Hungary

Crew
2

Production
73
UNITS


National flag of Austria National flag of the Austro-Hungarian Empire National flag of Hungary Austria-Hungary
(OPERATORS list includes past, present, and future operators when applicable)
Ground Attack (Bombing, Strafing)
Ability to conduct aerial bombing of ground targets by way of (but not limited to) guns, bombs, missiles, rockets, and the like.
Intelligence-Surveillance-Reconnaissance (ISR), Scout
Surveil ground targets / target areas to assess environmental threat levels, enemy strength, or enemy movement.


Length
31.2 ft
(9.50 m)
Width/Span
50.5 ft
(15.40 m)
Height
12.3 ft
(3.75 m)
Empty Wgt
2,013 lb
(913 kg)
MTOW
2,998 lb
(1,360 kg)
Wgt Diff
+985 lb
(+447 kg)
(Showcased structural values pertain to the base Lohner B.VII production variant)
Installed: 1 x Austro-Daimler inline engine developing 150 horsepower.
Max Speed
85 mph
(137 kph | 74 kts)
Ceiling
11,483 ft
(3,500 m | 2 mi)
Range
112 mi
(180 km | 333 nm)
Rate-of-Climb
350 ft/min
(107 m/min)


♦ MACH Regime (Sonic)
Sub
Trans
Super
Hyper
HiHyper
ReEntry
RANGES (MPH) Subsonic: <614mph | Transonic: 614-921 | Supersonic: 921-3836 | Hypersonic: 3836-7673 | Hi-Hypersonic: 7673-19180 | Reentry: >19030


(Showcased performance specifications pertain to the base Lohner B.VII production variant. Performance specifications showcased above are subject to environmental factors as well as aircraft configuration. Estimates are made when Real Data not available. Compare this aircraft entry against any other in our database or View aircraft by powerplant type)
OPTIONAL:
Up to 180 lb of conventional drop ordnance.


Supported Types


Graphical image of an aircraft conventional drop bomb munition


(Not all ordnance types may be represented in the showcase above)
B.I - Early War Model; unarmed
B.II - Differing engine
B.III - Differing engine
B.IV - Differing engine
B.V - Differing engine
B.VI - Differing engine
B.VII - Unarmed Model; fitted with Austro-Daimler engine of 150 or 160 horsepower; 73 examples produced; appearing August 1915.
C.I - Fitted with Austro-Daimler engine of 160 horsepowwer; armed with 1 x machine gun in rear cockpit (trainable mounting); engine cowling; 40 examples produced; appearing 1916.


Military lapel ribbon for Operation Allied Force
Military lapel ribbon for the Arab-Israeli War
Military lapel ribbon for the Battle of Britain
Military lapel ribbon for the Battle of Midway
Military lapel ribbon for the Berlin Airlift
Military lapel ribbon for the Chaco War
Military lapel ribbon for the Cold War
Military lapel ribbon for the Cuban Missile Crisis
Military lapel ribbon for pioneering aircraft
Military lapel ribbon for the Falklands War
Military lapel ribbon for the French-Indochina War
Military lapel ribbon for the Golden Age of Flight
Military lapel ribbon for the 1991 Gulf War
Military lapel ribbon for the Indo-Pak Wars
Military lapel ribbon for the Iran-Iraq War
Military lapel ribbon for the Korean War
Military lapel ribbon for the 1982 Lebanon War
Military lapel ribbon for the Malayan Emergency
Military lapel ribbon representing modern aircraft
Military lapel ribbon for the attack on Pearl Harbor
Military lapel ribbon for the Six Day War
Military lapel ribbon for the Soviet-Afghan War
Military lapel ribbon for the Spanish Civil War
Military lapel ribbon for the Suez Crisis
Military lapel ribbon for the Ukranian-Russian War
Military lapel ribbon for the Vietnam War
Military lapel ribbon for Warsaw Pact of the Cold War-era
Military lapel ribbon for the WASP (WW2)
Military lapel ribbon for the World War 1
Military lapel ribbon for the World War 2
Military lapel ribbon for the Yom Kippur War
Military lapel ribbon for experimental x-plane aircraft


Ribbon graphics not necessarily indicative of actual historical campaign ribbons. Ribbons are clickable to their respective aerial campaigns / operations / aviation periods.

Images Gallery



1 / 1
Image of the Lohner B.VII
Left side profile illustration of the Lohner B.VII biplane
