The Arado Ar Projekt II was a proposed jet-powered fighter of considerable size. It carried a basic classification of nightfighter / all-weather fighter and appeared in paper form towards the end of the European Campaign. The aircraft featured several cutting-edge design aspects that included swept-back wings, wing-mounted jet engines, a pressurized crew cabin (complete with side-by-side seating for two and ejection seats) and a retractable tricycle landing gear system. The main gears would recess into the tubular fuselage while the nose gear disappeared just under the cockpit seating area.
Design was traditional in the jet-fighter sense with an aerodynamic featureless fuselage. The engines were mounted under each wing just past the wing roots and would have been either 2 x HeS 011A series or 2 x BMW 003A series turbojet engines (a performance speed of 466 miles per hour was estimated). Wings were monoplanes and shoulder-mounted high up on the fuselage just aft of the cockpit. The fuselage ended in a point with tail planes also featuring swept back design and a single vertical tail surface. Armament was intended to be 4 x MK 108 series 30mm cannons with two mounted high on the nose and two mounted underneath the nose.
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.
(OPERATORS list includes past, present, and future operators when applicable)
✓Air-to-Air Combat, Fighter
General ability to actively engage other aircraft of similar form and function, typically through guns, missiles, and/or aerial rockets.
✓X-Plane (Developmental, Prototype, Technology Demonstrator)
Aircraft developed for the role of prototyping, technology demonstration, or research / data collection.
56.8 ft (17.30 m)
49.1 ft (14.98 m)
(Showcased structural values pertain to the base Arado Ar Projekt II production variant)
monoplane / shoulder-mounted / swept-back
Design utilizes a single primary wing mainplane; this represent the most popular mainplane arrangement.
Mainplanes are mounted at the upper section of the fuselage, generally at the imaginary line intersecting the pilot's shoulders.
The planform features wing sweep back along the leading edges of the mainplane, promoting higher operating speeds.
(Structural descriptors pertain to the base Arado Ar Projekt II production variant)
2 x HeS 011A OR 2 x BMW 003A-1 turbojet engines.
(Showcased performance specifications pertain to the base Arado Ar Projekt II production variant. Performance specifications showcased above are subject to environmental factors as well as aircraft configuration. Estimates are made when Real Data not available. Compare this aircraft entry against any other in our database or View aircraft by powerplant type)
2 x MK 108 30mm cannons in upper nose assembly.
2 x MK 108 30mm cannons in lower nose assembly.
(Not all ordnance types may be represented in the showcase above)
Hardpoint Mountings: 0
Projekt II - Development Series Designation.
