Voisin Type 5


Light Biplane Bomber Aircraft [ 1915 ]



The Voisin 5 could mount a single 7.7mm machine gun or a 37mm cannon in the bow gun position.



Authored By: Staff Writer | Last Edited: 12/01/2016 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

GO TO SPECIFICATIONS [+]
Advertisements
The French Voisin Type 5 bomber was developed from the proven Voisin III series and saw action in the First World War. Though the III series accomplished what was expected from it, it soon became apparent that aircraft with larger bomb loads were more appropriate for the changing face of the fronts. The III series was used as the basis of a new class of bomber featuring a stronger airframe and more powerful engines among other subtle engineering changes. This new development was now classified as the Voisin Type 5 and served for a time alongside the III models eventually replacing them on the production lines. Valued for a short time, the Type 5 was eventually relegated to bomber training and limited bombing sorties.

On the whole, the Voisin Type 5 (or simply "Voisin 5" or "Type 5") was a single engine aircraft powered by a "pusher-type" propeller arrangement mounted to the rear of a central nacelle. Wings were of the biplane variety - with the top assembly shifted forward - and stemmed from the rear of the nacelle over and under the engine placement. The empennage consisted of Vee-shaped cable-and-strut arrangement leading to the extreme rear where a single vertical tail fin was located, crossing an elongated elevator. The undercarriage was of a quadruple type and remained static in flight, one wheel to a landing gear strut. Seating consisted of a single pilot/gunner/bombardier seated in the forward portion of the nacelle just forward of the engine mounting. This forward position - offering up unparalleled views - held the standard primary armament that consisted of a single 7.7mm machine gun or a 1 x 37mm cannon. Up to 132 pounds of external stores in the form of bombs could be carried. Aside from this base Type 5 model, other developments included an experimental twin engine model appearing for a short time. This particular airframe was used to test a "pusher-puller" engine design layout approach (one engine pulling the aircraft whilst the other pushed it along) to the existing airframe but apparently came to naught.

In action, the Type 5 held its own for the most part but were not very highly sought after by pilots as the weapon she was marketed to be. Despite the beneficial additions and changes to the III series design, the Type 5 was not that much better than the design it replaced. Performance gains were minimal and the increase in power led only to a small increase in overall payload capacity. In the end, yet another attempt at a pusher-type aircraft produced very little operational fruit for the system proved to have some very serious inherent drawbacks including susceptibility to rear attack (no defensive armament was afforded the rear as the engine took up this space) and a single crewmember was expected to fill three onboard roles at once. Other operators of quantitative note included Russia.©MilitaryFactory.com
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.
Advertisements

Specifications



Service Year
1915

Origin
France national flag graphic
France

Crew
1

Production
300
UNITS


National flag of France National flag of Russia National flag of Switzerland France; Imperial Russia; Switzerland
(OPERATORS list includes past, present, and future operators when applicable)
Ground Attack (Bombing, Strafing)
Ability to conduct aerial bombing of ground targets by way of (but not limited to) guns, bombs, missiles, rockets, and the like.


Length
31.3 ft
(9.53 m)
Width/Span
48.4 ft
(14.75 m)
Height
11.9 ft
(3.63 m)
Empty Wgt
1,433 lb
(650 kg)
MTOW
2,513 lb
(1,140 kg)
Wgt Diff
+1,080 lb
(+490 kg)
(Showcased structural values pertain to the base Voisin Type 5 production variant)
Installed: 1 x Salmson (Canton-Unne) 9-cylinder liquid-cooled radial engine developing 150hp.
Max Speed
65 mph
(105 kph | 57 kts)
Ceiling
11,483 ft
(3,500 m | 2 mi)
Range
186 mi
(300 km | 556 nm)


♦ MACH Regime (Sonic)
Sub
Trans
Super
Hyper
HiHyper
ReEntry
RANGES (MPH) Subsonic: <614mph | Transonic: 614-921 | Supersonic: 921-3836 | Hypersonic: 3836-7673 | Hi-Hypersonic: 7673-19180 | Reentry: >19030


(Showcased performance specifications pertain to the base Voisin Type 5 production variant. Performance specifications showcased above are subject to environmental factors as well as aircraft configuration. Estimates are made when Real Data not available. Compare this aircraft entry against any other in our database or View aircraft by powerplant type)
1 x 7.7mm machine gun OR 1 x 37mm cannon at nose.

Up to 132lb of externally-carried drop munitions.


Supported Types


Graphical image of an aircraft medium machine gun
Graphical image of an aircraft automatic cannon
Graphical image of an aircraft conventional drop bomb munition


(Not all ordnance types may be represented in the showcase above)
Hardpoint Mountings: 2


LAS - Formal Factory Designation
Type 5 - Base Series Designation


Military lapel ribbon for Operation Allied Force
Military lapel ribbon for the Arab-Israeli War
Military lapel ribbon for the Battle of Britain
Military lapel ribbon for the Battle of Midway
Military lapel ribbon for the Berlin Airlift
Military lapel ribbon for the Chaco War
Military lapel ribbon for the Cold War
Military lapel ribbon for the Cuban Missile Crisis
Military lapel ribbon for pioneering aircraft
Military lapel ribbon for the Falklands War
Military lapel ribbon for the French-Indochina War
Military lapel ribbon for the Golden Age of Flight
Military lapel ribbon for the 1991 Gulf War
Military lapel ribbon for the Indo-Pak Wars
Military lapel ribbon for the Iran-Iraq War
Military lapel ribbon for the Korean War
Military lapel ribbon for the 1982 Lebanon War
Military lapel ribbon for the Malayan Emergency
Military lapel ribbon representing modern aircraft
Military lapel ribbon for the attack on Pearl Harbor
Military lapel ribbon for the Six Day War
Military lapel ribbon for the Soviet-Afghan War
Military lapel ribbon for the Spanish Civil War
Military lapel ribbon for the Suez Crisis
Military lapel ribbon for the Ukranian-Russian War
Military lapel ribbon for the Vietnam War
Military lapel ribbon for Warsaw Pact of the Cold War-era
Military lapel ribbon for the WASP (WW2)
Military lapel ribbon for the World War 1
Military lapel ribbon for the World War 2
Military lapel ribbon for the Yom Kippur War
Military lapel ribbon for experimental x-plane aircraft


Ribbon graphics not necessarily indicative of actual historical campaign ribbons. Ribbons are clickable to their respective aerial campaigns / operations / aviation periods.

Images Gallery



1 / 1
Image of the Voisin Type 5
