Lockheed C-69 Constellation (Model L-049)


Long-Range Transport / Electronic Warfare Aircraft (EWA)


United States | 1945



"The Lockheed C-69 Constellation would earn more fame as a passenger transport than in its militarized counterpart."



Authored By: Staff Writer | Last Edited: 05/30/2024 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site; No A.I. was used in the generation of this content.
The Lockheed Constellation series of aircraft was a successful design that initially began as a militarized transport, appearing in limited numbers towards the end of World War two, that gained more fame in the civilian transport airliner role soon after. The system was based on the military concept of long-range transport and refined design, incorporating various elements into the fold that would produce one of Lockheed's most memorable models.

The Constellation in any form was powered by four Wright radial engines. Crew accommodations amounted to four personnel and passenger seating varied - depending on model - from 60 to 80. The design of the aircraft sprouted to fulfill a need in the burgeoning airliner market, particularly with Pan American Airways along with Transcontinental and Western Air, for a long range passenger transport system that could truly be used for lengthy journeys throughout the United States. Initial models were flown as early as 1943 though the end of the war saw just 22 examples delivered for military use. By then, production lines had already begun focusing on the domestic transport market with the arrival of the 60-passenger L-049 model. From then on, the series would see an increase to the passenger count, numerous powerplant refinements and the lengthening of the fuselage to produce the "Super Constellation".

The base L749 passenger model allowed for a crew of four personnel and an additional 81 passengers. Powered by four Wright 749C-18BD-1 Double Cyclone air-cooled radial engines, the aircraft could achieve top speeds of over 340 miles per hour and reach a service ceiling of up to 24,000 feet. The fuselage design was taken into account to provide for a super-refined and streamlined look with the most identifiable feature becoming the three fin tail assembly. One revolutionary design element became the use of a tricycle landing gear system that offered up passenger comfort when taxiing and landing and returned better on-ground performance as a whole.

Beyond the passenger models, the Constellation lived on in militarized electronic warfare and reconnaissance variants. The long-range capabilities and internal carrying capacity opened the series up to some specialized roles that became the PO-1 and VW-2 "Warning Star" systems that went on to become a grouping of EC-121 electronic warfare systems (Constellation systems were later redesignated to C-121). Global coverage assigned to these systems included patrols over the North Atlantic and Pacific Oceans in a Cold War defense role. In the end, Lockheed produced yet another winner thanks to its experience in wartime design. This time, however, the firm made its mark with a passenger transport that became a revolutionary design thanks to its long-range capability.

Content ©MilitaryFactory.com; No Reproduction Permitted.
Power & Performance
Those special qualities that separate one aircraft design from another. Performance specifications presented assume optimal operating conditions for the Lockheed L749 Constellation Long-Range Transport / Electronic Warfare Aircraft (EWA).
4 x Wright 749C-18BD-1 Double Cyclone air-cooled radial engines developing 2,500 horsepower.
Propulsion
346 mph
557 kph | 301 kts
Max Speed
35,715 ft
10,886 m | 7 miles
Service Ceiling
2,000 miles
3,218 km | 1,738 nm
Operational Range
City-to-City Ranges
Operational range when compared to distances between major cities (in KM).
NYC

  LON
LON

  PAR
PAR

  BER
BER

  MOS
MOS

  TOK
TOK

  SYD
SYD

  LAX
LAX

  NYC
Structure
The nose-to-tail, wingtip-to-wingtip physical qualities of the Lockheed L749 Constellation Long-Range Transport / Electronic Warfare Aircraft (EWA).
4
(MANNED)
Crew
95.2 ft
29.03 m
O/A Length
123.0 ft
(37.49 m)
O/A Width
23.7 ft
(7.21 m)
O/A Height
60,953 lb
(27,648 kg)
Empty Weight
105,000 lb
(47,627 kg)
MTOW
Design Balance
The three qualities reflected below are altitude, speed, and range. The more full the box, the more balanced the design.
RANGE
ALT
SPEED
Variants
Notable series variants as part of the Lockheed C-69 Constellation (Model L-049) family line.
C-69 - Transport Variant; Base Series Designation.
L-49 - US Army Tranport Variant
L-049 - 60-Passenger Civil Airliner Production Model.
L-649 - 81-Passenger Civil Airliner Production Model; fitted with Wright 749C-18BD-1 radial engines (x4).
L-749 - Passenger Civil Airliner; increased fuel capacity.
L-1049 "Super Constellation" - Lengthened fuselage; 109-Passenger Civil Airliner Production Model.
L-1649 - Increased wing span; Fitted with Wright 988TC-18EA-2 radial engines; increased fuel capacity; increased range.
C-121 - Transport Variant based on the L-749.
R7O - Naval Transport Variant based on the L-1049.
PO-1 - Early Warning Radar Aircraft Variant
VW-2 "Warning Star" - Early Warning Radar Aircraft Variant.
EC-121 - Electronic Warfare Variant Aircraft.
Operators
Global customers who have evaluated and/or operated the Lockheed C-69 Constellation (Model L-049). Nations are displayed by flag, each linked to their respective national aircraft listing.

Total Production: 856 Units

Contractor(s): Lockheed - USA
National flag of the United States

[ United States (retired) ]
Relative Max Speed
Hi: 400mph
Lo: 200mph
Aircraft Max Listed Speed (346mph).

Graph Average of 300 MPH.
Era Crossover
Pie graph section
Pie graph section
Showcasing Aircraft Era Crossover (if any)
Max Alt Visualization
Small airplane graphic
Production Comparison
856
36183
44000
Entry compared against Ilyushin IL-2 (military) and Cessna 172 (civilian) total production.
MACH Regime (Sonic)
Sub
Trans
Super
Hyper
HiHyper
ReEntry
RANGES (MPH) Subsonic: <614mph | Transonic: 614-921 | Supersonic: 921-3836 | Hypersonic: 3836-7673 | Hi-Hypersonic: 7673-19180 | Reentry: >19030
Aviation Timeline
EarlyYrs
WWI
Interwar
WWII
ColdWar
Postwar
Modern
Future
1 / 10
Image of the Lockheed C-69 Constellation (Model L-049)
