Henschel Hs 129


Close-Support / Anti-Tank Ground Attack Aircraft [ 1942 ]



The Henschel Hs 129 fulfilled the all-important role of close-support strike aircraft for the German Luftwaffe during World War 2.



Authored By: Staff Writer | Last Edited: 04/26/2021 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

GO TO SPECIFICATIONS [+]
Advertisements
The Henschel Hs 129 fighter-bomber was built to a 1937 German specification for a twin-engine close-support aircraft with considerable armor protection for pilot and crew and the ability to field twin 20mm cannons at least. The resulting competition left a Focke-Wulf design (the Fw 189C) and the Henschel Hs 129 design as finalists with the nod going to the Henschel firm.

The Hs 129 was by far a perfect aircraft for close-support duty. It was relatively underpowered - even with the twin Gnome-Rhone radial engines - and the cockpit small enough to cram just one person. Visibility was reported to be far from superior though something about the overall design likened the Reichsluftahrtministerium to it. Armament consisted of two nose-mounted MG FF 20mm cannons and two MG 17 7.92mm machine guns. The Hs 129V-1 prototypes gave birth to ten Hs 129B-0 developmental models which, in turn, produced the initial Hs 129B-1 production series. The Hs 129 was immediately fielded to the Eastern Front to take on the divisions of Russian armor in force.

By 1942, the Hs 129B-2 came about as a need to "up-gun" the existing Hs 129B-1 production models. The B-2 became a series that varied in armament provisions that would include the R1, which was fielded with 2 x 20mm cannons and 2 x 13mm machine guns, and the R3 which removed the machine guns in favor of a larger caliber 37mm gun along with the standard twin 20mm cannons. The B-3 model series would produce 25 or so with the larger 75mm gun system and would become the final production Hs 129 systems in service.

The Hs 129 was fielded in the East against the might of the Soviet Union by design, though later they were consequently fielded throughout North Africa and Europe (post D-Day) by necessity. By all accounts, performance results of the system proved sublime, with the Hs 129 accounting for the destruction of hundreds of Soviet tanks, particularly at the Battle of Kursk in 1943. The Hs 129 proved to be a viable asset in the close-support role, capable of engaging even the most stubborn of Allied armor with an array of cannons, machine guns and bombs.©MilitaryFactory.com
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.
Advertisements

Specifications



Service Year
1942

Origin
Nazi Germany national flag graphic
Nazi Germany

Status
RETIRED
Not in Service.
Crew
1

Production
865
UNITS


National flag of modern Germany National flag of Nazi Germany National flag of Hungary National flag of Romania Hungary; Nazi Germany; Romania
(OPERATORS list includes past, present, and future operators when applicable)
Ground Attack (Bombing, Strafing)
Ability to conduct aerial bombing of ground targets by way of (but not limited to) guns, bombs, missiles, rockets, and the like.
Close-Air Support (CAS)
Developed to operate in close proximity to active ground elements by way of a broad array of air-to-ground ordnance and munitions options.


Length
32.0 ft
(9.75 m)
Width/Span
46.6 ft
(14.20 m)
Height
10.7 ft
(3.25 m)
Empty Wgt
8,400 lb
(3,810 kg)
MTOW
11,266 lb
(5,110 kg)
Wgt Diff
+2,866 lb
(+1,300 kg)
(Showcased structural values pertain to the Henschel Hs 129B-1/R2 production variant)
Installed: 2 x Gnome-Rhone 14M-4/5 14-cylinder radial engines developing 700 horsepower each driving three-bladed propeller units.
Max Speed
253 mph
(407 kph | 220 kts)
Ceiling
29,528 ft
(9,000 m | 6 mi)
Range
429 mi
(690 km | 1,278 nm)
Rate-of-Climb
1,595 ft/min
(486 m/min)


♦ MACH Regime (Sonic)
Sub
Trans
Super
Hyper
HiHyper
ReEntry
RANGES (MPH) Subsonic: <614mph | Transonic: 614-921 | Supersonic: 921-3836 | Hypersonic: 3836-7673 | Hi-Hypersonic: 7673-19180 | Reentry: >19030


(Showcased performance specifications pertain to the Henschel Hs 129B-1/R2 production variant. Performance specifications showcased above are subject to environmental factors as well as aircraft configuration. Estimates are made when Real Data not available. Compare this aircraft entry against any other in our database or View aircraft by powerplant type)
STANDARD:
2 x 20mm MG 151/20 cannons
2 x 13mm MG 131 machine guns

OPTIONAL:
Up to 900lb of conventional drop ordnance OR 1 x 30mm MK 191 gun pod.


Supported Types


Graphical image of an aircraft medium machine gun
Graphical image of an aircraft automatic cannon
Graphical image of an aircraft machine gun pod
Graphical image of an aircraft conventional drop bomb munition


(Not all ordnance types may be represented in the showcase above)
Hardpoint Mountings: 8


Hs 129V-1 - Prototype Model
Hs 129B-0 - Developmental Model; fitted with 2 x 20mm MG 151/20 cannons and 2 x 7.92mm MG 17 machine guns; ten such models produced.
Hs 192B-1 - Initial Production Model
Hs 129B-2
Hs 129B-2/R1 - Fitted with 2 x 20mm cannons and 2 x 13mm machine guns.
Hs 129B-2/R3 - Fitted with 2 x 20mm cannons amd 1 x 37mm BK 3.7 cannon.
Hs 129B-3 - Final Production Variant Model; 25 such models produced; fitted with electro-pneumatic 75mm BK cannon.
Hs 129C - Proposed improved form; never completed nor produced.


General Assessment
Firepower
Performance
Survivability
Versatility
Impact
Values are derrived from a variety of categories related to the design, overall function, and historical influence of this aircraft in aviation history.
Overall Rating
The overall rating takes into account over 60 individual factors related to this aircraft entry.
72
Rating is out of a possible 100 points.
Relative Maximum Speed
Hi: 300mph
Lo: 150mph
This entry's maximum listed speed (253mph).

Graph average of 225 miles-per-hour.
City-to-City Ranges
NYC

  LON
LON

  PAR
PAR

  BER
BER

  MOS
MOS

  TOK
TOK

  SYD
SYD

  LAX
LAX

  NYC
Henschel Hs 129B-1/R2 operational range when compared to distances between major cities (in KM).
Max Altitude Visualization
Small airplane graphic
Design Balance
The three qualities reflected above are altitude, speed, and range.
Aviation Era Span
Pie graph section
Showcasing era cross-over of this aircraft design.
Unit Production (865)
865
36183
44000
Compared against Ilyushin IL-2 (military) and Cessna 172 (civilian).
>>

Military lapel ribbon for Operation Allied Force
Military lapel ribbon for the Arab-Israeli War
Military lapel ribbon for the Battle of Britain
Military lapel ribbon for the Battle of Midway
Military lapel ribbon for the Berlin Airlift
Military lapel ribbon for the Chaco War
Military lapel ribbon for the Cold War
Military lapel ribbon for the Cuban Missile Crisis
Military lapel ribbon for pioneering aircraft
Military lapel ribbon for the Falklands War
Military lapel ribbon for the French-Indochina War
Military lapel ribbon for the Golden Age of Flight
Military lapel ribbon for the 1991 Gulf War
Military lapel ribbon for the Indo-Pak Wars
Military lapel ribbon for the Iran-Iraq War
Military lapel ribbon for the Korean War
Military lapel ribbon for the 1982 Lebanon War
Military lapel ribbon for the Malayan Emergency
Military lapel ribbon representing modern aircraft
Military lapel ribbon for the attack on Pearl Harbor
Military lapel ribbon for the Six Day War
Military lapel ribbon for the Soviet-Afghan War
Military lapel ribbon for the Spanish Civil War
Military lapel ribbon for the Suez Crisis
Military lapel ribbon for the Ukranian-Russian War
Military lapel ribbon for the Vietnam War
Military lapel ribbon for Warsaw Pact of the Cold War-era
Military lapel ribbon for the WASP (WW2)
Military lapel ribbon for the World War 1
Military lapel ribbon for the World War 2
Military lapel ribbon for the Yom Kippur War
Military lapel ribbon for experimental x-plane aircraft


Ribbon graphics not necessarily indicative of actual historical campaign ribbons. Ribbons are clickable to their respective aerial campaigns / operations / aviation periods.

Images Gallery



1 / 7
Image of the Henschel Hs 129
