Beechcraft C-45 (Expeditor)


Utility / Trainer Aircraft [ 1941 ]



The United States Army Air Corps took on the civilian-minded Beechcraft Model 18 as the C-45 in 1939.



Authored By: Staff Writer | Last Edited: 08/26/2017 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

VIEW SPECIFICATIONS [+]
The Beechcraft C-45 was based on the Beech Aircraft Corporation's civilian-minded Model 18 "Twin Beech" series. First flight for the original company design was recorded on January 15th, 1937 and the aircraft was introduced that same year attempting to find its place in the peacetime market. Ultimately, with the onset of world war on the horizon, the US military adopted the Model 18 in many guises including the United States Army Air Forces (USAAF) which designated the type as the "C-45". It went on to become a fixture within the inventories of the USAAF (later the USAF), the US Navy and the USMC and saw additional service overseas with British and Canadian forces through Lend-Lease. In all, some 9,000 Model 18 aircraft were built covering 32 different variants in the family line. Production spanned from 1937 to 1970. While the Model 18 served as the basis for the C-45, it was also the origin of the "Navigator" and "Kansan" lines of the USAAF/USAF and the USN/USMC. The C-45 went on to see considerable operational service in World War 2 and the Korean War in the light transport, VIP transport and mission liaison roles.

Externally, the Model 18 was a basic design featuring a short nose assembly, framed cockpit position, tapered fuselage, low-set wing assemblies and a n H-style tail unit. The engines were fitted into streamlined nacelles at each wing leading edge. The undercarriage consisted of a tail-dragging arrangement to include two main landing gear legs and a tail wheel. Power was served through the pairing of Pratt & Whitney R-985 Wasp Junior radial piston engines of 450 horsepower each powering twin-bladed propellers. This supplied a maximum speed of 225 miles per hour with a cruising speed nearing 211 miles per hour. Range was out to 1,200 miles with a service ceiling of approximately 18,500 feet. The standard operating crew for a single C-45 was two pilots and up to nine passengers depending on the internal cabin configuration. Additionally, the cabin space could also be optimized for photo-reconnaissance equipment, MEDEVAC and light cargo-hauling. Overall, however, there proved no notable differences between the military C-45 and civilian Model 18 airframe.©MilitaryFactory.com
The US Army Air Corps eventually placed orders for over 1,300 C-45 aircraft and, of these, most (1,137) were delivered in the C-45F configuration (seven-seat passenger transport). Other variants included the original C-45, the C-45A, C-45B, C-45C, C-45D, C-45E, C-45G and C-45H models - differing mainly in internal configuration and expected role. The "Expeditor II" and "Expeditor III" names were given to British (Royal Navy) and Canadian (Air Force) examples, respectively, under Lend-Lease.

After World War 2 and into the volatile 1950s, the US military charged Beechcraft with refurbishing some 900 C-45 airframes and these were reconstituted into USAF service as the C-45G (autopilot, R-985-AN-3 radial engines) and C-45H (sans autopilot, R-985-AN-14B engines) of which many went on to serve into the 1960s (approx. 1963). Some were assigned to Strategic Air Command (SAC).

Every branch of American service eventually fielded some form of the Model 18, such was the reach of this fine little airplane.©MilitaryFactory.com
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.

Specifications



Service Year
1941

Origin
United States national flag graphic
United States

Crew
2 + 7

Production
1,300
UNITS


Beech Aircraft Corporation - USA
(View other Aviaton-Related Manufacturers)
National flag of Canada National flag of the United Kingdom National flag of the United States Canada; United Kingdom; United States
(OPERATORS list includes past, present, and future operators when applicable)
Transport
General transport functionality to move supplies/cargo or personnel (including wounded and VIP) over range.
VIP Service
Used in the Very-Important-Person (VIP) passenger transport role, typically with above-average amenities and luxuries as standard.


Length
34.2 ft
(10.41 m)
Width/Span
47.7 ft
(14.53 m)
Height
9.7 ft
(2.95 m)
Empty Wgt
6,173 lb
(2,800 kg)
MTOW
7,496 lb
(3,400 kg)
Wgt Diff
+1,323 lb
(+600 kg)
(Showcased structural values pertain to the Beechcraft UC-45 (Expeditor) production variant)
Installed: 2 x Pratt & Whitney R-985-AN-1 Wasp Junior radial engines delivering 450 horsepower each.
Max Speed
224 mph
(360 kph | 194 kts)
Ceiling
26,017 ft
(7,930 m | 5 mi)
Range
1,181 mi
(1,900 km | 3,519 nm)
Rate-of-Climb
1,850 ft/min
(564 m/min)


♦ MACH Regime (Sonic)
Sub
Trans
Super
Hyper
HiHyper
ReEntry
RANGES (MPH) Subsonic: <614mph | Transonic: 614-921 | Supersonic: 921-3836 | Hypersonic: 3836-7673 | Hi-Hypersonic: 7673-19180 | Reentry: >19030


(Showcased performance specifications pertain to the Beechcraft UC-45 (Expeditor) production variant. Performance specifications showcased above are subject to environmental factors as well as aircraft configuration. Estimates are made when Real Data not available. Compare this aircraft entry against any other in our database or View aircraft by powerplant type)
None.


Supported Types




(Not all ordnance types may be represented in the showcase above)
C-45 - Six-seat transport model; 11 examples produced.
C-45A - Eight seat multi-purpose transport model; 20 examples produced.
C-45B - Based on C18S model; 223 examples produced; later redesignated to UC-45.
C-45C - Based on 18S model
C-45F - Based on C18S; seven-seat passenger transport; later redesignated to UC-45F.


Military lapel ribbon for Operation Allied Force
Military lapel ribbon for the Arab-Israeli War
Military lapel ribbon for the Battle of Britain
Military lapel ribbon for the Battle of Midway
Military lapel ribbon for the Berlin Airlift
Military lapel ribbon for the Chaco War
Military lapel ribbon for the Cold War
Military lapel ribbon for the Cuban Missile Crisis
Military lapel ribbon for pioneering aircraft
Military lapel ribbon for the Falklands War
Military lapel ribbon for the French-Indochina War
Military lapel ribbon for the Golden Age of Flight
Military lapel ribbon for the 1991 Gulf War
Military lapel ribbon for the Indo-Pak Wars
Military lapel ribbon for the Iran-Iraq War
Military lapel ribbon for the Korean War
Military lapel ribbon for the 1982 Lebanon War
Military lapel ribbon for the Malayan Emergency
Military lapel ribbon representing modern aircraft
Military lapel ribbon for the attack on Pearl Harbor
Military lapel ribbon for the Six Day War
Military lapel ribbon for the Soviet-Afghan War
Military lapel ribbon for the Spanish Civil War
Military lapel ribbon for the Suez Crisis
Military lapel ribbon for the Ukranian-Russian War
Military lapel ribbon for the Vietnam War
Military lapel ribbon for Warsaw Pact of the Cold War-era
Military lapel ribbon for the WASP (WW2)
Military lapel ribbon for the World War 1
Military lapel ribbon for the World War 2
Military lapel ribbon for the Yom Kippur War
Military lapel ribbon for experimental x-plane aircraft


Ribbon graphics not necessarily indicative of actual historical campaign ribbons. Ribbons are clickable to their respective aerial campaigns / operations / aviation periods.

Images Gallery



1 / 15
Image of the Beechcraft C-45 (Expeditor)
