AirCo DH.9


Light Bomber Biplane Aircraft [ 1917 ]



The planned successor to the Airco DH.4, the Airco DH.9 failed in most respects.



Authored By: Staff Writer | Last Edited: 05/16/2018 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

VIEW SPECIFICATIONS [+]
The AirCo DH.9 was a further revision of the DH.4 bomber - again headed by famous aviation engineer Geoffrey de Havilland. Design of the new aircraft was handled by the de Havilland company with serial production managed through the Aircraft Manufacturing Company, better known under the acronym of "AirCo" or "Airco". The model was first flown in July of 1917 and introduced into service that same year. It managed only a short post-war career as it was retired from notable service in 1920. 4,091 of the type were ultimately produced.

The DH.9 shared a few of the major design qualities found on the preceding DH.4 including the undercarriage, tail unit, and wings. The DH.9 differed from the DH.4 in that it positioned the gunner and pilot closer together to better communications between the two and was fitted with a more powerful engine. The new fuselage was also intended to streamline the aircraft and take away stresses from the engine. Initial tests revealed that the base DH.9 was simply too underpowered and not much of an upgrade over the DH.4 (which it was meant to replace) thus the system was redesigned as the DH.9A. The DH.9A model attempted to address performance issues and defensive drawbacks by incorporating a lengthened wingspan and a fixed forward-firing machine gun for the pilot. A trainable machine gun was found at the rear gunner/observer's cockpit for protecting the aircraft's critical "six" position.

Not a spectacular aircraft in any one regard, the DH.9 managed a rather poor service record in World War 1 with more losses due to mechanical and performance issues than actual enemy fire. Notable deficiencies in the series lay in its limited service ceiling, fuel consumption at altitudes higher than 10,000 feet, and general engine reliability. If there was one role that the DH.9 proved at least somewhat adequate in was in coastal patrol assignments when hunting down German U-boats - there was a reduced chance of running into enemy aircraft or ground-based fire in this role. Though generally inadequate over most fronts, the DH.9 was naturally more successful in poorly defended areas during the course of the war, this to be true in the Middle East Theater over Palestine and also over Macedonia.

The DH.9 series saw some life after the war in the civil transportation market with many countries. Final production of the DH.9 extended into 1920 - the United States manufactured the DH.9 with the help of the Engineering Division and designated the aircraft as "USD-9" (1,415 were produced by the U.S.). An American-produced engine - the 400 horsepower Packard "Liberty" - was used to power these DH.9A models.©MilitaryFactory.com
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.

Specifications



Aircraft Manufacturing Company Ltd (AirCo) / de Havilland - United Kingdom
Manufacturer(s)
Afghanistan; Australia; Belgium; Bolivia; Canada; Chile; Denmark; Estonia; Greece; India; Ireland; Latvia; Netherlands; New Zealand; Paraguay; Peru; Poland; Romania; Saudi Arabia (Kingdom of Hejaz); Spain; South Africa; Soviet Union; Switzerland; Turkey; United Kingdom; United States
Operators National flag of Afghanistan National flag of Australia National flag of Belgium National flag of Bolivia National flag of Canada National flag of Chile National flag of Denmark National flag of Estonia National flag of Greece National flag of India National flag of Ireland National flag of Latvia National flag of the Netherlands National flag of New Zealand National flag of Peru National flag of Poland National flag of Romania National flag of the Kingdom of Saudi Arabia National flag of South Africa National flag of the Soviet Union National flag of Spain National flag of Switzerland National flag of Turkey National flag of the United Kingdom National flag of the United States
1917
Service Year
United Kingdom
National Origin
Retired
Project Status
2
Crew
4,091
Units


GROUND ATTACK
Ability to conduct aerial bombing of ground targets by way of (but not limited to) guns, bombs, missiles, rockets, and the like.


30.4 ft
(9.27 meters)
Length
65.4 ft
(19.92 meters)
Width/Span
11.3 ft
(3.44 meters)
Height
2,235 lb
(1,014 kilograms)
Empty Weight
3,799 lb
(1,723 kilograms)
Maximum Take-Off Weight
+1,563 lb
(+709 kg)
Weight Difference


1 x Armstrong Siddeley Puma water-cooled inline piston engine developing 230 horsepower.
Propulsion
113 mph
(182 kph | 98 knots)
Max Speed
15,518 ft
(4,730 m | 3 miles)
Ceiling
503 miles
(810 km | 437 nm)
Range
540 ft/min
(165 m/min)
Rate-of-Climb


MACH Regime (Sonic)
Sub
Trans
Super
Hyper
HiHyper
ReEntry
RANGES (MPH) Subsonic: <614mph | Transonic: 614-921 | Supersonic: 921-3836 | Hypersonic: 3836-7673 | Hi-Hypersonic: 7673-19180 | Reentry: >19030


STANDARD:
1 x .303 Vickers machine gun in fixed, forward-firing mounting.
1 OR 2 x .303 Lewis machine gun(s) in rear cockpit position on trainable Scarff ring mounting.

OPTIONAL:
External bomb load up to 460 lb (209 kg).


4
Hardpoints


DH.9 - Base production model based on the earlier DH.4 with decreased area between pilot and gunner positions of which over 3,000 produced.
DH.9A - Improved powerplant
DH.9B - Civilian Conversion Model to accommodate pilot and two passengers.
DH.9C - Civilian Conversion Model to accommodate pilot and three passengers.
DH.9J - Updated powerplant (Armstrong Siddeley Jaguar III radial piston engine generating 385-hp); Pilot trainer.
DH.9J M'pala I - Conversion for South Africa fitted with Bristol Jupiter VI radial piston engine generating 450hp.
M'pala II - Conversion model for South Africa fitted with Bristol Jupiter VIII radial piston engine generating 480hp.
Mantis - Conversion model for South Africa fitted with Wolseley Viper piston engine generating 200hp.


Military lapel ribbon for Operation Allied Force
Military lapel ribbon for the Arab-Israeli War
Military lapel ribbon for the Battle of Britain
Military lapel ribbon for the Battle of Midway
Military lapel ribbon for the Berlin Airlift
Military lapel ribbon for the Chaco War
Military lapel ribbon for the Cold War
Military lapel ribbon for the Cuban Missile Crisis
Military lapel ribbon for pioneering aircraft
Military lapel ribbon for the Falklands War
Military lapel ribbon for the French-Indochina War
Military lapel ribbon for the Golden Age of Flight
Military lapel ribbon for the 1991 Gulf War
Military lapel ribbon for the Indo-Pak Wars
Military lapel ribbon for the Iran-Iraq War
Military lapel ribbon for the Korean War
Military lapel ribbon for the 1982 Lebanon War
Military lapel ribbon for the Malayan Emergency
Military lapel ribbon representing modern aircraft
Military lapel ribbon for the attack on Pearl Harbor
Military lapel ribbon for the Six Day War
Military lapel ribbon for the Soviet-Afghan War
Military lapel ribbon for the Spanish Civil War
Military lapel ribbon for Special Forces
Military lapel ribbon for the Suez Crisis
Military lapel ribbon for the Ukranian-Russian War
Military lapel ribbon for the Vietnam War
Military lapel ribbon for Warsaw Pact of the Cold War-era
Military lapel ribbon for the WASP (WW2)
Military lapel ribbon for the World War 1
Military lapel ribbon for the World War 2
Military lapel ribbon for the Yom Kippur War
Military lapel ribbon for experimental x-plane aircraft

Images



1 / 3
Image of the AirCo DH.9
