Focke-Wulf Fw BMW802 (Fw 190)


High-Altitude, High-Performance Fighter Study [ 1943 ]



The Focke-Wulf Fw BMW802 was a design study into the feasibility of mounting the powerful BMW802 radial into the existing Fw 190 airframe.



Authored By: Staff Writer | Last Edited: 08/03/2019 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

GO TO SPECIFICATIONS [+]
Advertisements
Even as World War 2 (1939-1945) was in full swing in 1941, design studies undertaken by German engineers were looking to exact additional power and performance from existing combat fighter types. One viable candidate became the classic Focke-Wulf Fw 190 piston-engined fighter which was only just introduced in August of that year and these studies looked to further the fortunes of the war for Germany. An offshoot project of this aircraft was an entry which attempted to showcase the feasibility of adding the still in-development BMW 802 series 18-cylinder, supercharged, twin-row, air-cooled radial piston engine in place of the original radial installation (at its core the new engine was essentially an 18-cylinder form of the earlier 14-cylinder offering). However, the project - recognized generically as the Fw "BMW 802" - did not advanced beyond the paper stage.

The Fw BMW 802 proposal retained the complete aft fuselage section, tail unit, undercarriage, and cockpit of the original Fw 190 production fighter. The major changes were to the nose and wing mainplanes. The nose was now intended to mount the powerful new engine which was set to take up a considerable amount of space, forcing the nose section to be extended well-beyond the cockpit which, in turn, was forced further back in the design - reducing forward visibility. As the new engine was still air-cooled, a cut-off nose was used for aspiration and the complete unit drove a conventional three-bladed propeller unit (variable pitch) in tractor fashion. A traditional tail-dragger undercarriage would be used for ground-running.

The wing mainplanes were revised to sport dihedral (upward angle) just outboard of the main landing gear leg housings. Furthermore, these members were lengthened due to the performance expected out of the new, faster fighter (similar to what was done in the Focke-Wulf Ta 152 high-altitude fighter seen before war's end). The wings were given little sweepback at their leading edges and tapered considerably towards the rounded tips from thee trailing edges. As the position of these members was also ahead of the pilot, frontal vision was further hindered.

In terms of armament, no weapons set was finalized though it can be assumed that there would have been a permanent switch to all-cannons, perhaps fitted to the wings in pairs, to provide the fighter with excellent killing power and clear the nose section for the large engine. Additionally, a limited bomb-carrying capability can be suspected - with the typical three-hardpoints available to most every fighter of the war - a single point under the fuselage and one position under each wing. In addition to this, the hardpoints would have most likely been plumbed for jettisonable fuel tanks when needing to extend the aircraft's operational range.

The promising fuel-injected BMW 802 offered up to 2,600 horsepower initially and settled near 1,600 horsepower and had the potential to truly increase all performance aspects of the Fw 190 fighter. However, it was not run until 1943 as its development proved troublesome and lengthy, ultimately leading to its abandonment in favor of furthering turbojet engine technology. As such, any advanced fighter form intending to fit the BMW 802 was abandoned in turn.

A more evolved version of the Fw BMW 802, designated the "P.8011", intended to fit a modified version of the same BMW 802 engine in the nose to drive contra-rotating propeller units. Many qualities of the original Fw BMW 802 were to be carried over in this entry but neither advanced into anything worthwhile.

In any event, the high-performance, high-altitude role was eventually filled by such types as the Ta 152 (detailed elsewhere on this site).©MilitaryFactory.com
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.
Advertisements

Specifications



Service Year
1943

Origin
Nazi Germany national flag graphic
Nazi Germany

Status
CANCELLED
Development Ended.
Crew
1

Production
0
UNITS


National flag of modern Germany National flag of Nazi Germany Nazi Germany (cancelled)
(OPERATORS list includes past, present, and future operators when applicable)
Air-to-Air Combat, Fighter
General ability to actively engage other aircraft of similar form and function, typically through guns, missiles, and/or aerial rockets.
Interception
Ability to intercept inbound aerial threats by way of high-performance, typically speed and rate-of-climb.
Close-Air Support (CAS)
Developed to operate in close proximity to active ground elements by way of a broad array of air-to-ground ordnance and munitions options.
X-Plane (Developmental, Prototype, Technology Demonstrator)
Aircraft developed for the role of prototyping, technology demonstration, or research / data collection.


Length
37.7 ft
(11.50 m)
Width/Span
41.0 ft
(12.50 m)
Height
12.5 ft
(3.80 m)
Empty Wgt
9,921 lb
(4,500 kg)
MTOW
11,905 lb
(5,400 kg)
Wgt Diff
+1,984 lb
(+900 kg)
(Showcased structural values pertain to the Focke-Wulf Fw BMW802 production variant)
Installed: 1 x BMW 802 18-cylinder, supercharged, twin-row, air-cooled engine developing 2,600 horsepower and driving a three-bladed propeller unit at the nose.
Max Speed
450 mph
(725 kph | 391 kts)
Ceiling
41,010 ft
(12,500 m | 8 mi)


♦ MACH Regime (Sonic)
Sub
Trans
Super
Hyper
HiHyper
ReEntry
RANGES (MPH) Subsonic: <614mph | Transonic: 614-921 | Supersonic: 921-3836 | Hypersonic: 3836-7673 | Hi-Hypersonic: 7673-19180 | Reentry: >19030


(Showcased performance specifications pertain to the Focke-Wulf Fw BMW802 production variant. Performance specifications showcased above are subject to environmental factors as well as aircraft configuration. Estimates are made when Real Data not available. Compare this aircraft entry against any other in our database or View aircraft by powerplant type)
ASSUMED, FIXED, FORWARD-FIRING:
4 x 20mm MG151 automatic cannons in wings (two per wing member).

ASSUMED, OPTIONAL:
2 x 110lb conventional drop bombs, one under each wing.

Up to 1,105lb of conventional drop stores across three hardpoints (under belly, one each under wing) as required. Also support for jettisonable fuel tanks across all three hardpoints.


Supported Types


Graphical image of an aircraft automatic cannon
Graphical image of an aircraft conventional drop bomb munition
Graphical image of an aircraft external fuel tank


(Not all ordnance types may be represented in the showcase above)
Hardpoint Mountings: 3


Fw BMW802 - Base Project Designation; design work only; powered by the BMW 802 18-cylinder engine in revised nose section of an Fw 190 fighter airframe.
P.8011 - Advanced project incorporating modified BMW802 of 2,900 horsepower driving 2 x Three-bladed propellers in contra-rotating fashion.


Military lapel ribbon for Operation Allied Force
Military lapel ribbon for the Arab-Israeli War
Military lapel ribbon for the Battle of Britain
Military lapel ribbon for the Battle of Midway
Military lapel ribbon for the Berlin Airlift
Military lapel ribbon for the Chaco War
Military lapel ribbon for the Cold War
Military lapel ribbon for the Cuban Missile Crisis
Military lapel ribbon for pioneering aircraft
Military lapel ribbon for the Falklands War
Military lapel ribbon for the French-Indochina War
Military lapel ribbon for the Golden Age of Flight
Military lapel ribbon for the 1991 Gulf War
Military lapel ribbon for the Indo-Pak Wars
Military lapel ribbon for the Iran-Iraq War
Military lapel ribbon for the Korean War
Military lapel ribbon for the 1982 Lebanon War
Military lapel ribbon for the Malayan Emergency
Military lapel ribbon representing modern aircraft
Military lapel ribbon for the attack on Pearl Harbor
Military lapel ribbon for the Six Day War
Military lapel ribbon for the Soviet-Afghan War
Military lapel ribbon for the Spanish Civil War
Military lapel ribbon for the Suez Crisis
Military lapel ribbon for the Ukranian-Russian War
Military lapel ribbon for the Vietnam War
Military lapel ribbon for Warsaw Pact of the Cold War-era
Military lapel ribbon for the WASP (WW2)
Military lapel ribbon for the World War 1
Military lapel ribbon for the World War 2
Military lapel ribbon for the Yom Kippur War
Military lapel ribbon for experimental x-plane aircraft


Ribbon graphics not necessarily indicative of actual historical campaign ribbons. Ribbons are clickable to their respective aerial campaigns / operations / aviation periods.

Images Gallery



1 / 1
Image of the Focke-Wulf Fw BMW802 (Fw 190)
