Dassault MD.117-33


Swing-Wing Mach 3 Interceptor [ 1965 ]



The proposed French-originated Dassault MD.117-33 project intended to use a swing-wing feature for super-high-speed flight.



Authored By: Staff Writer | Last Edited: 03/21/2019 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

GO TO SPECIFICATIONS [+]
Advertisements
At the end of World War 2 in 1945, the French aero-industry lay in ruins. The German occupation hampered and ultimately destroyed many pre-war and early-war programs and it was the task of several remaining industry players to resurrect a once-thriving industry. Dassault Aviation, established back in 1929 by Marcel Dassault (nee Bloch), was one of the contributors in bringing back French aviation from the dead and many-a-project were developed in the post-war period around the growing acceptance of the turbojet engine.

The concept of the "swing-wing", or variable-sweep wing, was another product of the post-war period. In this arrangement, the mainplanes, or a section of them, could be swept in-flight as needed. The arrangement proved the cornerstone of Cold War (1947-1991) designs such as the American Grumman F-14 "Tomcat" naval fighter and European PANAVIA "Tornado" fighter-bomber (both detailed elsewhere on this site). The ability to "sweep the wing" forward or rearward provided different lift-and-drag properties for different portions of an aircraft's flight envelope - wings with little sweep being optimal for low-speed, low-level flight while increasingly swept-back wings were needed for high-speed flight.

Dassault was one of the few (possibly the only one) French concerns that made any notable progress in this field with several developments based around the concept of a "moving wing". One such product of the period became the "MD.117-33" which most likely appeared during the 1960s as a "paper" airplane. In this proposed fighter/interceptor design, the aircraft had a typical centered, cylindrical fuselage of rather slim form with extended wingroots housing what would become the variable geometry wing controls. The mainplanes were seated well-aft of midships with the cockpit closer to the nose and a single-finned vertical plane used at the tail, which also made use of low-mounted horizontal planes. For ground-running, the aircraft was drawn up with a modern retractable tricycle undercarriage.

The cockpit was to offer relatively good views of the action around the front of the aircraft, though this would be obstructed some by the raised dorsal spine directly behind the seat. Ahead of the cockpit was a slim nosecone most likely to house a radar unit. The canopy was of a two-piece design with light framing and an ejection seat most likely would have been worked into the aircraft at some point.

One of the most distinguishable physical characteristics of this proposed Mach 3.0+ single-seat, twin-engine fighter aircraft were its podded turbojet-housing nacelles. These were installed as close to the body to either side of the fuselage and under the large-area wingroots. Shock cones were featured at their intake ends and exhausting was through conventional circular ports.

Despite the promise offered of this super-high-speed aircraft on paper, there appeared too many design issues to overcome for the MD.117-33 to become a viable player. Notable concerns centered on proper balancing, general air flow, structural integrity of individual parts and sections of the aircraft at super-high-speeds, general engine positioning and arrangement in the overall fighter, and the basic concept of a Mach 3+ capable fighter/interceptor to cover the modest French airspace. With all of that, it appears that the project was not advanced beyond a single official three-view drawing.©MilitaryFactory.com
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.
Advertisements

Specifications



Service Year
1965

Origin
France national flag graphic
France

Status
CANCELLED
Development Ended.
Crew
1

Production
0
UNITS


National flag of France France (cancelled)
(OPERATORS list includes past, present, and future operators when applicable)
Air-to-Air Combat, Fighter
General ability to actively engage other aircraft of similar form and function, typically through guns, missiles, and/or aerial rockets.
Interception
Ability to intercept inbound aerial threats by way of high-performance, typically speed and rate-of-climb.
X-Plane (Developmental, Prototype, Technology Demonstrator)
Aircraft developed for the role of prototyping, technology demonstration, or research / data collection.


Length
60.4 ft
(18.40 m)
Width/Span
47.2 ft
(14.40 m)
(Showcased structural values pertain to the base Dassault MD.117-33 production variant)
Installed: 2 x Turbojet engines of unknown make and model.
Max Speed
2,302 mph
(3,705 kph | 2,001 kts)
Ceiling
80,052 ft
(24,400 m | 15 mi)


♦ MACH Regime (Sonic)
Sub
Trans
Super
Hyper
HiHyper
ReEntry
RANGES (MPH) Subsonic: <614mph | Transonic: 614-921 | Supersonic: 921-3836 | Hypersonic: 3836-7673 | Hi-Hypersonic: 7673-19180 | Reentry: >19030


(Showcased performance specifications pertain to the base Dassault MD.117-33 production variant. Performance specifications showcased above are subject to environmental factors as well as aircraft configuration. Estimates are made when Real Data not available. Compare this aircraft entry against any other in our database or View aircraft by powerplant type)
None disclosed.


Supported Types




(Not all ordnance types may be represented in the showcase above)
MD.117-33 - Base Project Designation.


Military lapel ribbon for Operation Allied Force
Military lapel ribbon for the Arab-Israeli War
Military lapel ribbon for the Battle of Britain
Military lapel ribbon for the Battle of Midway
Military lapel ribbon for the Berlin Airlift
Military lapel ribbon for the Chaco War
Military lapel ribbon for the Cold War
Military lapel ribbon for the Cuban Missile Crisis
Military lapel ribbon for pioneering aircraft
Military lapel ribbon for the Falklands War
Military lapel ribbon for the French-Indochina War
Military lapel ribbon for the Golden Age of Flight
Military lapel ribbon for the 1991 Gulf War
Military lapel ribbon for the Indo-Pak Wars
Military lapel ribbon for the Iran-Iraq War
Military lapel ribbon for the Korean War
Military lapel ribbon for the 1982 Lebanon War
Military lapel ribbon for the Malayan Emergency
Military lapel ribbon representing modern aircraft
Military lapel ribbon for the attack on Pearl Harbor
Military lapel ribbon for the Six Day War
Military lapel ribbon for the Soviet-Afghan War
Military lapel ribbon for the Spanish Civil War
Military lapel ribbon for the Suez Crisis
Military lapel ribbon for the Ukranian-Russian War
Military lapel ribbon for the Vietnam War
Military lapel ribbon for Warsaw Pact of the Cold War-era
Military lapel ribbon for the WASP (WW2)
Military lapel ribbon for the World War 1
Military lapel ribbon for the World War 2
Military lapel ribbon for the Yom Kippur War
Military lapel ribbon for experimental x-plane aircraft


Ribbon graphics not necessarily indicative of actual historical campaign ribbons. Ribbons are clickable to their respective aerial campaigns / operations / aviation periods.

Images Gallery



1 / 1
Image of the Dassault MD.117-33
