Blackburn B.48 / YA.1 (Firecrest)


Carrier-based Naval Strike Fighter Prototype Aircraft [ 1947 ]



Just three of the proposed Blackburn Firecrest strike fighters were completed for Britain in the late-1940s, the project ultimately cancelled when little could be had from the design.



Authored By: Staff Writer | Last Edited: 06/07/2019 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

VIEW SPECIFICATIONS [+]
During World War 2 (1939-1945), constant issues in the development of the Blackburn "Firebrand" single-seat, single-engine navy strike fighter (detailed elsewhere on this site) ensured that the type would have an uphill battle in reaching operational capability (indeed it entered service only after the war in 1945 and, in the end, only 220 were acquired by the British Royal Navy (RN)). This led the Blackburn engineering team to pursue an all-new design to shore up the Firebrand's limitations and this work ultimately produced the Blackburn "Firecrest", also recognized under the designations of "B-48" and "Y.A.1". The Firecrest would undertake the same type of carrier-based strike roles envisioned for the Firebrand and also serve the RN's Fleet Air Arm (FAA) if it could prove itself a sounder product.

Air Ministry Specification S.28/43 was established for the development of the Firecrest ("Firecrest" was its unofficial name) and three flyable prototypes were commissioned.

To go along with the "clean-sheet" approach, the design team worked on an all-new wing structure in 1943 promising performance and stability gains. The engine of choice became the Bristol "Centaurus" series and this was set to drive a pair of contra-rotating propellers at the nose. Proposed armament was 2 x 20mm automatic cannons and a bomb load of up to 1,800lb. Both streamlined and lighter-in-weight when compared to the Firebrand, the Firecrest was, at least on paper, already proving itself a better investment.

Like the Firebrand before it, the Firecrest also fought through a troubled development period as it suffered from ever-changing service requirements which worked against the aircraft to the point that only two of the three ordered prototypes were ever flown - and these served as simple data-collecting platforms. The third went on to see life as a strength-testing subject. Before the end, the Firecrest's structure was reworked for the rigors of naval attack operations and the engine was changed to another installation once the contra-rotating propeller quality was dropped. These sorts of revisions naturally affected other components of the aircraft to the point that the design became something of a complicated mess at every turn.

Ground tests finally occurred in February of 1947 though, by this point, World War 2 had been over for some time (mid-1945). A first flight was had on April 1st, 1947 and, in this form, the aircraft featured a relatively deep fuselage and sat its pilot (under a bubble canopy) towards the nose for better out-of-the-cockpit vision (a strong quality to have for carrier-based combat aircraft). The wing mainplanes (with noticeable dihedral) were set ahead of midships and the tail unit consisted of a single fin and low-set horizontal planes. A traditional "tail-dragger" wheeled undercarriage was fitted (retractable). The propeller unit at the nose sported a large spinner. Dimensions included a length of 39.3 feet, a wingspan of 44.11 feet and a height of 14.5 feet. Weight was 10,515lb against a Maximum Take-Off Weight (MTOW) of 15,300lb.

The aircraft carried the Bristol Centaurus 59 series 18-cylinder air-cooled radial piston engine of 2,475 horsepower and this driving a five-bladed propeller. Maximum speed was 612 miles per hour with cruising near 215 mph. Range was out to 900 miles and the service ceiling reached 31,600 feet. Rate-of-climb was 2,500 feet-per-minute.

Proposed armament was 2 x 12.7mm M2 Browning heavy machine guns at the wings and support for 8 x RP-3 rockets and 1 x 2,100lb torpedo (under the fuselage) or 2 x 250lb drop bombs (under the wings).

The first prototype was marked "RT651" and ended its days back in the hands of the Blackburn company when the Air Ministry had completed its flying tests (it was later scrapped). The second prototype became "RT656" and was used in structure tests before being scrapped in 1952. "VF172", the third airframe of the lot, soldiered on as a research platform, testing out the intricacies of power-boosted ailerons during 1948 and was sold back to Blackburn the following year only to join her sisters in being scrapped.

Beyond its troubled development phase, the Firecrest was further rendered obsolete with the arrival of the jet age and all-new turboprop technology which promised far greater gains than what the Firecrest could offer - limiting its development to just the three mentioned prototypes. Other similar platforms of the period to reach varying levels of operational success included the Westland "Wyvern" and the American Martin AM "Mauler" and classic Douglas AD "Skyraider" - all detailed elsewhere on this site.©MilitaryFactory.com
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.

Specifications



Service Year
1947

Origin
United Kingdom national flag graphic
United Kingdom

Status
CANCELLED
Development Ended.
Crew
1

Production
3
UNITS


National flag of the United Kingdom United Kingdom (cancelled)
(OPERATORS list includes past, present, and future operators when applicable)
Air-to-Air Combat, Fighter
General ability to actively engage other aircraft of similar form and function, typically through guns, missiles, and/or aerial rockets.
Ground Attack (Bombing, Strafing)
Ability to conduct aerial bombing of ground targets by way of (but not limited to) guns, bombs, missiles, rockets, and the like.
Close-Air Support (CAS)
Developed to operate in close proximity to active ground elements by way of a broad array of air-to-ground ordnance and munitions options.
Maritime / Navy
Land-based or shipborne capability for operating over-water in various maritime-related roles while supported by allied naval surface elements.
X-Plane (Developmental, Prototype, Technology Demonstrator)
Aircraft developed for the role of prototyping, technology demonstration, or research / data collection.


Length
39.4 ft
(12.00 m)
Width/Span
44.9 ft
(13.70 m)
Height
14.5 ft
(4.42 m)
Empty Wgt
10,582 lb
(4,800 kg)
MTOW
14,650 lb
(6,645 kg)
Wgt Diff
+4,068 lb
(+1,845 kg)
(Showcased structural values pertain to the Blackburn B.48 production variant)
Installed: 1 x Bristol Centaurus 59 18-cylinder air-cooled radial piston engine developing 2,475 horsepower and driving a five-bladed propeller unit at the nose.
Max Speed
382 mph
(615 kph | 332 kts)
Ceiling
31,594 ft
(9,630 m | 6 mi)
Range
901 mi
(1,450 km | 783 nm)
Rate-of-Climb
2,500 ft/min
(762 m/min)


♦ MACH Regime (Sonic)
Sub
Trans
Super
Hyper
HiHyper
ReEntry
RANGES (MPH) Subsonic: <614mph | Transonic: 614-921 | Supersonic: 921-3836 | Hypersonic: 3836-7673 | Hi-Hypersonic: 7673-19180 | Reentry: >19030


(Showcased performance specifications pertain to the Blackburn B.48 production variant. Performance specifications showcased above are subject to environmental factors as well as aircraft configuration. Estimates are made when Real Data not available. Compare this aircraft entry against any other in our database or View aircraft by powerplant type)
PROPOSED, FIXED, STANDARD:
2 x 0.50 caliber Browning M2 heavy machine guns at the wings.
8 x RP-3 air-to-surface rockets held under the wings.

OPTIONAL:
1 x 2,100lb torpedo under fuselage centerline OR 2 x 250lb drop bombs under wings.


Supported Types


Graphical image of an aircraft medium machine gun
Graphical image of an aircraft heavy machine gun
Graphical image of aircraft aerial rockets
Graphical image of an aircraft conventional drop bomb munition
Graphical image of an aircraft aerial torpedo


(Not all ordnance types may be represented in the showcase above)
Hardpoint Mountings: 3


B.48 - Base Series Designation.
"Firecrest" - Unofficial nickname.
YA.1 - SBAC designation.
RT651 - First prototype.
RT656 - Second prototype.
VF172 - Third prototype.


Military lapel ribbon for Operation Allied Force
Military lapel ribbon for the Arab-Israeli War
Military lapel ribbon for the Battle of Britain
Military lapel ribbon for the Battle of Midway
Military lapel ribbon for the Berlin Airlift
Military lapel ribbon for the Chaco War
Military lapel ribbon for the Cold War
Military lapel ribbon for the Cuban Missile Crisis
Military lapel ribbon for pioneering aircraft
Military lapel ribbon for the Falklands War
Military lapel ribbon for the French-Indochina War
Military lapel ribbon for the Golden Age of Flight
Military lapel ribbon for the 1991 Gulf War
Military lapel ribbon for the Indo-Pak Wars
Military lapel ribbon for the Iran-Iraq War
Military lapel ribbon for the Korean War
Military lapel ribbon for the 1982 Lebanon War
Military lapel ribbon for the Malayan Emergency
Military lapel ribbon representing modern aircraft
Military lapel ribbon for the attack on Pearl Harbor
Military lapel ribbon for the Six Day War
Military lapel ribbon for the Soviet-Afghan War
Military lapel ribbon for the Spanish Civil War
Military lapel ribbon for the Suez Crisis
Military lapel ribbon for the Ukranian-Russian War
Military lapel ribbon for the Vietnam War
Military lapel ribbon for Warsaw Pact of the Cold War-era
Military lapel ribbon for the WASP (WW2)
Military lapel ribbon for the World War 1
Military lapel ribbon for the World War 2
Military lapel ribbon for the Yom Kippur War
Military lapel ribbon for experimental x-plane aircraft


Ribbon graphics not necessarily indicative of actual historical campaign ribbons. Ribbons are clickable to their respective aerial campaigns / operations / aviation periods.

Images Gallery



1 / 1
Image of the Blackburn B.48 / YA.1 (Firecrest)
