Bell Model 212


Medium-Lift Utility / Transport Helicopter [ 1968 ]



Produced from 1968 until 1998, the Bell Model 212 helicopter found homes in many inventories spanning several global operators.



Authored By: Staff Writer | Last Edited: 07/02/2020 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

GO TO SPECIFICATIONS [+]
Advertisements
The Bell Model 212 helicopter ("Twin Two-Twelve") was originally developed by Bell Helicopters for the Canadian military under the designation of CUH-1N (to become the CH-135 "Twin Huey" in service). It was based on the established framework of the earlier Bell Model 205 helicopter product which was, itself, developed along with the Bell Model 204 as civilian market offshoots of the successful military "Huey" line (the Model 212 closely associated with the UH-1N). As in those designs, the Model 212 relied on a single-engine configuration and had a twin-bladed main rotor and twin-bladed tail rotor unit. It eventually found a modest stable of global customers that included Canada, Colombia, Croatia, Germany (West Germany), Greece, Japan, Serbia, Slovenia, Thailand and the United States.

The Model 212 achieved first-flight in 1968 and was introduced that same year. Production then spanned from 1968 until 1998. Back in 1988, manufacture of the series moved from the United States to Canada (though still produced under the Bell Helicopter brand label).

In both form and function, the Model 212 was indicative of the whole Huey line. It featured its crew of one or two seated at front in a side-by-side arrangement. Automobile-style doors were granted to each crewman for easy entry-exit. The passenger cabin was designed to seat up to fourteen. Overall length of the aircraft was 57 feet with a rotor diameter of 48 feet and a height of 12.6 feet. Empty weight was 6,530lb against an MTOW of 11,200lb. Power was provided by a Pratt & Whitney Canada PT6T-3 (or PT6T-3B) turboshaft engine. This drove both the main rotor atop the cabin as well as the tail rotor (offset to portside) atop the vehicle tail fin. Output of this engine fit was 1,800 horsepower. Performance specifications included a maximum speed of 140 miles per hour and range was out to 240 nautical miles. Its service ceiling reached 17,400 feet with a rate-of-climb reaching 1,745 feet-per-minute.

The Model 412 was an offshoot of the Bell 212 line and incorporated a four-bladed main rotor as well as two engines in its make-up. Foreign (licensed) production of the Model 212 was taken up by Agusta-Bell of Italy (as the "AB212") and its Anti-Submarine Warfare (ASW) derivative became the "AB212 ASW". The Eagle 212 "Single" was a local Canadian development that substituted the PWC engine with the Lycoming T53-17 (or T53-BCV) turboshaft.

Model 212 helicopters continue to serve in several roles today despite their 1960s heritage - some with navy and coast guard services and others with police forces.©MilitaryFactory.com
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.
Advertisements

Specifications



Service Year
1968

Origin
United States national flag graphic
United States

Status
ACTIVE
In Active Service.
Crew
2

Production
550
UNITS


National flag of Canada National flag of Colombia National flag of Croatia National flag of Greece National flag of modern Japan National flag of Serbia National flag of Slovenia National flag of Thailand National flag of the United States Canada; Colombia; Croatia; Greece; Japan; Serbia; Slovenia; Thailand; United States
(OPERATORS list includes past, present, and future operators when applicable)
Ground Attack (Bombing, Strafing)
Ability to conduct aerial bombing of ground targets by way of (but not limited to) guns, bombs, missiles, rockets, and the like.
Close-Air Support (CAS)
Developed to operate in close proximity to active ground elements by way of a broad array of air-to-ground ordnance and munitions options.
Special-Mission: Search & Rescue (SAR)
Ability to locate and extract personnel from areas of potential harm or peril (i.e. downed airmen in the sea).
Transport
General transport functionality to move supplies/cargo or personnel (including wounded and VIP) over range.
Commercial Aviation
Used in roles serving the commercial aviation market, ferrying both passengers and goods over range.
VIP Service
Used in the Very-Important-Person (VIP) passenger transport role, typically with above-average amenities and luxuries as standard.
Intelligence-Surveillance-Reconnaissance (ISR), Scout
Surveil ground targets / target areas to assess environmental threat levels, enemy strength, or enemy movement.
Special Forces
Serving Special Forces / Special Operations elements and missions.


Length
57.3 ft
(17.45 m)
Width/Span
48.1 ft
(14.65 m)
Height
12.6 ft
(3.83 m)
Empty Wgt
6,614 lb
(3,000 kg)
MTOW
11,199 lb
(5,080 kg)
Wgt Diff
+4,586 lb
(+2,080 kg)
(Showcased structural values pertain to the base Bell Model 212 production variant)
Installed: 2 x Pratt & Whitney Canada PT6T-3 OR PT6T-3B turboshaft engines developing 1,800 horsepower and driving a two-bladed main rotor and two-bladed tail rotor.
Max Speed
140 mph
(225 kph | 121 kts)
Ceiling
17,405 ft
(5,305 m | 3 mi)
Range
273 mi
(440 km | 815 nm)
Rate-of-Climb
1,745 ft/min
(532 m/min)


♦ MACH Regime (Sonic)
Sub
Trans
Super
Hyper
HiHyper
ReEntry
RANGES (MPH) Subsonic: <614mph | Transonic: 614-921 | Supersonic: 921-3836 | Hypersonic: 3836-7673 | Hi-Hypersonic: 7673-19180 | Reentry: >19030


(Showcased performance specifications pertain to the base Bell Model 212 production variant. Performance specifications showcased above are subject to environmental factors as well as aircraft configuration. Estimates are made when Real Data not available. Compare this aircraft entry against any other in our database or View aircraft by powerplant type)
Typically none though militarized gunship forms can sport door-mounted 7.62mm machine guns on pintles and wingstubs can support rocket pods.


Supported Types


Graphical image of an aircraft medium machine gun
Graphical image of aircraft aerial rockets
Graphical image of an aircraft rocket pod


(Not all ordnance types may be represented in the showcase above)
Model 212 - Base Series Designation.


Military lapel ribbon for Operation Allied Force
Military lapel ribbon for the Arab-Israeli War
Military lapel ribbon for the Battle of Britain
Military lapel ribbon for the Battle of Midway
Military lapel ribbon for the Berlin Airlift
Military lapel ribbon for the Chaco War
Military lapel ribbon for the Cold War
Military lapel ribbon for the Cuban Missile Crisis
Military lapel ribbon for pioneering aircraft
Military lapel ribbon for the Falklands War
Military lapel ribbon for the French-Indochina War
Military lapel ribbon for the Golden Age of Flight
Military lapel ribbon for the 1991 Gulf War
Military lapel ribbon for the Indo-Pak Wars
Military lapel ribbon for the Iran-Iraq War
Military lapel ribbon for the Korean War
Military lapel ribbon for the 1982 Lebanon War
Military lapel ribbon for the Malayan Emergency
Military lapel ribbon representing modern aircraft
Military lapel ribbon for the attack on Pearl Harbor
Military lapel ribbon for the Six Day War
Military lapel ribbon for the Soviet-Afghan War
Military lapel ribbon for the Spanish Civil War
Military lapel ribbon for the Suez Crisis
Military lapel ribbon for the Ukranian-Russian War
Military lapel ribbon for the Vietnam War
Military lapel ribbon for Warsaw Pact of the Cold War-era
Military lapel ribbon for the WASP (WW2)
Military lapel ribbon for the World War 1
Military lapel ribbon for the World War 2
Military lapel ribbon for the Yom Kippur War
Military lapel ribbon for experimental x-plane aircraft


Ribbon graphics not necessarily indicative of actual historical campaign ribbons. Ribbons are clickable to their respective aerial campaigns / operations / aviation periods.

Images Gallery



1 / 1
Image of the Bell Model 212
