Boulton Paul Defiant


Twin-Seat, Single-Engine Interceptor / Night-fighter / Turret Fighter Aircraft [ 1939 ]



The Boulton Paul Defiant became a useful defensive-minded night-fighter platform primarily over Britian during World War 2.



Authored By: Staff Writer | Last Edited: 01/26/2021 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

GO TO SPECIFICATIONS [+]
Advertisements
The inter-war years saw a vast shift to more modern and potent aircraft platforms. The Boulton Paul Defiant followed as only the RAF's third such monoplane aircraft and, amazingly enough, the Defiant also became the RAF's first four machine gun fighter. The defiant arose from the Air Ministry Specification F.9/35, which called for a twin-seat monoplane fighter with all of its armament concentrated in rear-mounted, hydraulically powered dorsal turret. For whatever reason, warplanners were high on the idea of a fighter aircraft sporting a battery of concentrated fire power in a powered turret system. The idea being that the aircraft could maneuver its way into enemy bomber formations and wreak havoc with its excellent armament at will, all the while being able to protect itself from pesky enemy fighters.

Boulton Paul already had some experience in producing such a concept by building some 59 of Hawker's Demon aircraft in the early-to-mid 1930s. These aircraft were fighter developments of the Hawker Hart and sported an enclosed gun turret at the rearward portion of the fuselage. The turrets were designed by Frazer-Nash and proved to be a sound solution, allowing for heavy armament and better gun sights to be fitted and work in conjunction with the gunner's tendencies. Early forms of the turret were manually powered and drafty but external power sources and enclosures of frame and glass were soon developed to evolve the design to its more traditional form.

The Defiant was an interesting concept to say the least. In many ways, it harkened back to the days of World War 1, where scout airplanes were being armed for self-defense while being sent out over the Front to spy on enemy ground movements. These early aircraft sported simple defensive armaments in a rear-placed cockpit, providing the rear gunner with an adequate field-of-fire from trailing enemy fighters. In practice, this concept worked but it is still interesting to compare that line of early-century thinking with developments in the inter-war years nonetheless.

The first of two Defiant prototypes went airborne on August 11th, 1937 with an order of 400 following. However, only three were actually in RAF hands by the outset of World War 2. Within time, deliveries eventually built up No 264 Squadron and made them the first operational Defiant group on December 8th, 1939. The aircraft and her aircrews would have to wait till May 12th, 1940 to sample their first taste of combat against the German Luftwaffe. Early results proved promising as the aircraft served up no fewer than 65 enemy air kills before the end of May 1940 thanks to its excellent armament load.

The bread and butter of the Defiant system lay in its hydraulically-powered rear turret. Unsuspecting enemy pilots, thinking the Defiant was susceptible from attacks from the rear, were greeted with a hail of hot lead from the 4 x 7.7mm (.303 caliber) Browning air-cooled machine guns. The machine guns were paired two to a side and the entire turret system could scan a 360-degree area above the aircraft. Visibility was somewhat hampered by the heavy framing around the glassy enclosure but in theory, the layout was deemed acceptable. Six-hundred rounds of 7.7mm ammunition were afforded each gun, making for a staggering total of 2,400 rounds available to the gunner. Bringing the guns to bear successfully on an enemy aircraft usually yielded favorable results to Defiant crews, that is, should an enemy fighter pilot be foolish enough to contend with the aircraft from the rear.©MilitaryFactory.com
Advertisements
Despite these early successes, Luftwaffe crews eventually realized the limits of the Defiant design. The turret, despite its available firepower, proved to add substantial drag and weight to the limited Defiant airframe resulting in poor performance when compared to later Luftwaffe aerial implements. Performance was everything to a dog-fighting aircrew and the Defiant would not suffice in the role - at least not in the long term. Once it became common knowledge based on experience that the Defiant mounted no forward-facing defensive armament whatsoever, Luftwaffe crews made it their strategy to attack the aircraft from the front. Though the 4-gun armament of the Defiants could be brought to bear in the forward position, this was seldom the practice as protecting the aircraft's rear was grand priority for most Defiant crews. As expected, losses of the aircraft type began to mount to the point that the Defiant was pulled from daytime action in August of 1940.

All was not lost for the Defiant series however, as they were reinstituted back into action as converted night-fighters. Defiants were now were fielded with the new mark of Defiant NF.Mk I and were naturally based on the standard Mk I marks from earlier. The NF.Mk IA followed soon afterwards with the potent AI.Mk IV / VI interception radar systems for increased lethality in the dark of night. The British were already proving themselves masters with radar development and would utilize this expertise throughout its defensive parameter during the Battle of Britain. During the span of 1940 through 1941, the Defiant accounted for more enemy air kills than any other RAF aircraft could boast - an impressive statistic considering the RAF also had access to the durable Hurricanes and the excellent Spitfires. At its peak of use, no fewer than 13 RAF squadrons were fielding Defiants in the defensive role.

The Defiant Mk I sported a top speed of 304 miles per hour with a 404 mile range. The service ceiling was reported at approximately 30,350ft, making it comparable to other early forms of new monoplane fighters. Power was derived from a single Rolls-Royce brand Merlin III series liquid-cooled V12 piston engine of 1,030 horsepower. A total of 723 Mk I series fighters were produced.

The Defiant NF.Mk II followed the Mark I series into the fold. These were essentially improved versions of the previous base mark but were more dedicated platforms to fulfill the night-fighter role with differences including an increase to its vertical tail surface and the implementation of the AI Mk IV airborne interception radar. The Defiant NF.Mk II series sported specifications that were a bit different, with a top speed listed at 313 miles per hour and a service ceiling of 30,350 feet. Range was now increased to roughly a 465-mile range. Power was now derived from a single Rolls-Royce Merlin XX series piston engine of 1,280 horsepower. 210 total NF.Mk II models were produced.

Additional marks became the ASR.Mk I model series, these issued as air-sea rescue platforms fitted with dingies underside. The TT.Mk I's were nothing more than target tug conversion models of the Mk I series with some 150 converted for the role. The TT.Mk III were also target tug aircraft, though these were produced as 140 new-build systems sans the four-gun turret.

Despite its early successes and increasing losses to follow, the Defiant found a niche in the nightfighter role which suited it quite well. Advancements in night time radar no doubt helped to extend the life of the platform, as did Britain's need for more defensive measures. The lack of front-facing armament no doubt was a terrible oversight in the design, but Boulton Paul engineers did what they could with what they knew for the time. In the end, the Boulton Paul Defiant became a memorable part of military aviation history in what could very well have been a rocky and forgettable tale if events had dictated otherwise. Sadly, only one complete Boulton Paul Defiant example exists, this being appropriately held by the Royal Air Force Museum in Hendon, London.©MilitaryFactory.com
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.
Advertisements

Specifications



Service Year
1939

Origin
United Kingdom national flag graphic
United Kingdom

Status
RETIRED
Not in Service.
Crew
2

Production
1,075
UNITS


National flag of Australia National flag of Canada National flag of India National flag of Poland National flag of the United Kingdom National flag of the United States Australia; India; Canada; Poland; United Kingdom; United States (single example)
(OPERATORS list includes past, present, and future operators when applicable)
Air-to-Air Combat, Fighter
General ability to actively engage other aircraft of similar form and function, typically through guns, missiles, and/or aerial rockets.
Interception
Ability to intercept inbound aerial threats by way of high-performance, typically speed and rate-of-climb.


Length
35.3 ft
(10.77 m)
Width/Span
39.3 ft
(11.99 m)
Height
11.3 ft
(3.45 m)
Empty Wgt
6,281 lb
(2,849 kg)
MTOW
8,424 lb
(3,821 kg)
Wgt Diff
+2,143 lb
(+972 kg)
(Showcased structural values pertain to the Boulton Paul Defiant Mk II production variant)
Installed: 1 x Rolls-Royce Merlin XX piston engine developing 1,280 horsepower and driving three-bladed propeller unit at the nose.
Max Speed
313 mph
(504 kph | 272 kts)
Ceiling
30,348 ft
(9,250 m | 6 mi)
Range
465 mi
(748 km | 1,385 nm)
Rate-of-Climb
1,900 ft/min
(579 m/min)


♦ MACH Regime (Sonic)
Sub
Trans
Super
Hyper
HiHyper
ReEntry
RANGES (MPH) Subsonic: <614mph | Transonic: 614-921 | Supersonic: 921-3836 | Hypersonic: 3836-7673 | Hi-Hypersonic: 7673-19180 | Reentry: >19030


(Showcased performance specifications pertain to the Boulton Paul Defiant Mk II production variant. Performance specifications showcased above are subject to environmental factors as well as aircraft configuration. Estimates are made when Real Data not available. Compare this aircraft entry against any other in our database or View aircraft by powerplant type)
STANDARD:
4 x 7.7mm Browning machine guns in a hydraulically-powered rear turret.


Supported Types


Graphical image of an aircraft medium machine gun


(Not all ordnance types may be represented in the showcase above)
Hardpoint Mountings: 0


P.82 - Prototype Fighter Designation; examples produced.
Mk I - Fitted with Rolls-Royce Merlin III engine of 1,030 horsepower; 723 examples produced.
NF.Mk I - MK I models converted to night-fighter role.
NF.Mk IA - NF.MK I models with AI.Mk IV / VI radar system.
ASR.Mk I - Air-Sea Rescue model fitted to carry dingy boats for role.
TT.Mk I - Target Tug Conversions of Mk I model series; 150 converted.
NF.Mk II - Nightfighter variant with improved Merlin XX powerplant of 1,280 horsepower; increased vertical tail surface; AI Mk IV airborne interception radar; 210 examples produced.
TT.Mk III - Target-Tug Aircraft; 140 new-builds; sans turret.
