Mil Mi-17 (Hip-H)


Medium-Lift Transport Helicopter / Gunship [ 1981 ]



The Mil Mi-17 transport helicopter was born from the original Mi-8 series as an improved form.



Authored By: Staff Writer | Last Edited: 02/28/2022 | Content ©www.MilitaryFactory.com | The following text is exclusive to this site.

VIEW SPECIFICATIONS [+]
The original Mil Mi-8 "Hip" medium-lift transport helicopter series first flew in prototype form on July 7th, 1961 and was introduced in 1967. Since then, over 17,000 examples of the type have been produced while the series maintains an active presence within the inventories of many air services today (2015). The Mi-17 "Hip" model - based on the Mi-8M/MT variant of the Soviet/Russian military - was developed with exportation in mind and has been adopted by over twenty nations worldwide. The Mi-17 model achieved its own first flight in 1975 and was introduced in 1981. Notable serial production has been ongoing since 1977 with totals reaching around 12,000 units with production shared between the Mil Moscow Helicopter Plant as well as the Kazan Helicopter Plant.

Externally, the Mi-17 product shares many of the same features with its earlier cousin including a well-glazed cockpit offering good vision, sliding side doors access with rear loading ramp, and fixed wheeled tricycle undercarriage. One discernable difference is in the tail rotor mounting which now faces starboard instead of port side. The cockpit area has been given improved protection through additional armoring and larger Klimov TV3-117VM turboshaft engines have increased performance - the main rotor and gearbox are based on those developed for the Mi-14.

Beyond its traditional role of personnel/cargo hauler, the Mi-17 can be outfitted for the gunship role, typically through multi-shot rocket pods fitted along wing stub mountings. Other versions have been equipped for Search and Rescue (SAR), VIP/general passenger transport, high-altitude, MEDEVAC, Electronic Warfare (EW), and airborne Command Post (CP) service. It has seen its fair share of operations over active combat zones ranging from Cambodia and India/Pakistan to Columbia, Macedonia, and Sri Lanka. Mi-17s were used by both sides of the Libyan Civil War (2011) and the rebuilding Afghan Air Force relies heavily on its Mi-17 fleet.

Operators currently range from Afghanistan and Argentina to Sri Lanka and Thailand. China began local license production of the Mi-17 during May of 2008 and, despite its Cold War-era roots, the Mi-17 remains very much in play today with several nations still considering order of the type.

The base designation of the line is Mi-17 and it is known to NATO as "Hip-H". The Mi-8AMT based model is the Mi-17-1 for export. The Mi-17-1M is its high-altitude performance equivalent. The Mi-17-1VA serves in the airborne hospital role while the Mi-17-2 is the Mi-8MTV-2. The Mi-8MTV-3 becomes the Mi-17V-3 and the Mi-8MTV-5 is the Mi-17V-5. The Mi-17V-7 is outfitted with VK-2500 engines and its loading ramp has been replaced by clam shell-style doors. The Mi-17M was a test bed for what became the Mi-17MD (Mi-17V-5). New avionics greeted the Mi-7KF. Night operations support was brought to the Mi-17N. General passenger hauling service was through the Mi-17P variant. The Mi-8MTG became the export Mi-17PG. The Mi-17S serves as a VIP passenger model. Various other designs have been added to the Mi-17 product line.©MilitaryFactory.com
Note: The above text is EXCLUSIVE to the site www.MilitaryFactory.com. It is the product of many hours of research and work made possible with the help of contributors, veterans, insiders, and topic specialists. If you happen upon this text anywhere else on the internet or in print, please let us know at MilitaryFactory AT gmail DOT com so that we may take appropriate action against the offender / offending site and continue to protect this original work.

June 2018 - India's border security service has taken on six refurbished Mi-17V model helicopters from Russian Helicopters. The service utilized ten V-models for various border-related missions.

March 2020 - Peru is in line to acquire additional Mi-171 units in large numbers.

Specifications



Service Year
1981

Origin
Soviet Union national flag graphic
Soviet Union

Status
ACTIVE
In Active Service.
Crew
3

Production
12,000
UNITS


Mil Moscow Helicopter Plant - Soviet Union / Russian Helicopters / Kazan - Russia
(View other Aviaton-Related Manufacturers)
National flag of Afghanistan National flag of Argentina National flag of Bulgaria National flag of China National flag of Colombia National flag of Croatia National flag of India National flag of Iraq National flag of Libya National flag of Macedonia National flag of Malaysia National flag of Mexico National flag of North Korea National flag of Pakistan National flag of Russia National flag of Slovakia National flag of the Soviet Union National flag of Sri Lanka National flag of Sudan National flag of Thailand Afghanistan; Argentina; Bulgaria; Cambodia; China; Colombia; Croatia; India; Iraq; Kenya; Libya; Macedonia; Malaysia; Mexico; North Korea; Pakistan; Russia; Slovakia; Sri Lanka; South Sudan; Soviet Union; Thailand
(OPERATORS list includes past, present, and future operators when applicable)
Ground Attack (Bombing, Strafing)
Ability to conduct aerial bombing of ground targets by way of (but not limited to) guns, bombs, missiles, rockets, and the like.
Close-Air Support (CAS)
Developed to operate in close proximity to active ground elements by way of a broad array of air-to-ground ordnance and munitions options.
Special-Mission: MEDical EVACuation (MEDEVAC)
Extraction of wounded combat or civilian elements by way of specialized onboard equipment and available internal volume or external carrying capability.
Special-Mission: Search & Rescue (SAR)
Ability to locate and extract personnel from areas of potential harm or peril (i.e. downed airmen in the sea).
Transport
General transport functionality to move supplies/cargo or personnel (including wounded and VIP) over range.
Commercial Aviation
Used in roles serving the commercial aviation market, ferrying both passengers and goods over range.
VIP Service
Used in the Very-Important-Person (VIP) passenger transport role, typically with above-average amenities and luxuries as standard.


Length
60.5 ft
(18.45 m)
Width/Span
69.7 ft
(21.25 m)
Height
15.6 ft
(4.75 m)
Empty Wgt
16,535 lb
(7,500 kg)
MTOW
29,762 lb
(13,500 kg)
Wgt Diff
+13,228 lb
(+6,000 kg)
(Showcased structural values pertain to the base Mil Mi-17 (Hip-H) production variant)
monoplane / low-mounted / straight
Monoplane
Design utilizes a single primary wing mainplane; this represent the most popular mainplane arrangement.
Low-Mounted
Mainplanes are low-mounted along the sides of the fuselage.
Straight
The planform involves use of basic, straight mainplane members.
(Structural descriptors pertain to the base Mil Mi-17 (Hip-H) production variant)
Installed: 2 x Klimov TV3-117MT/VM OR VK-2500 turboshaft engines developing 2,100 shp or 2,700 shp respectively while driving five-bladed main rotor and three-bladed tail rotor.
Max Speed
158 mph
(255 kph | 138 kts)
Ceiling
19,685 ft
(6,000 m | 4 mi)
Range
360 mi
(580 km | 1,074 nm)
Rate-of-Climb
1,575 ft/min
(480 m/min)


♦ MACH Regime (Sonic)
Sub
Trans
Super
Hyper
HiHyper
ReEntry
RANGES (MPH) Subsonic: <614mph | Transonic: 614-921 | Supersonic: 921-3836 | Hypersonic: 3836-7673 | Hi-Hypersonic: 7673-19180 | Reentry: >19030


(Showcased performance specifications pertain to the base Mil Mi-17 (Hip-H) production variant. Performance specifications showcased above are subject to environmental factors as well as aircraft configuration. Estimates are made when Real Data not available. Compare this aircraft entry against any other in our database or View aircraft by powerplant type)
Typically none unless outfitted for gunship/armed transport role: Missiles (Shturm-V), rockets (S-8), rocket pods, 23mm cannon pods, and 7.62mm gun pods across underwing hardpoints when fitted wingstubs; 7.62mm machine guns at doors and / or rear of aircraft. Optional nose machine gun and fuel tanks.


Supported Types


Graphical image of an aircraft medium machine gun
Graphical image of an aircraft automatic cannon
Graphical image of an aircraft machine gun pod
Graphical image of an aircraft cannon pod
Graphical image of aircraft aerial rockets
Graphical image of an aircraft rocket pod
Graphical image of an aircraft external fuel tank


(Not all ordnance types may be represented in the showcase above)
Hardpoint Mountings: 6
Mounting Points




-
-
9
7
5
-
-
-
4
6
8
-
-
HARDPOINT(S) KEY:
X

15
13
11
9
7
5
3
1
2
4
6
8
10
12
14


COLOR KEY:
Fuselage Centerline
Fuselage Port/Wingroot
Fuselage Starboard/Wingroot
Wing/Underwing
Wingtip Mount(s)
Internal Bay(s)
Not Used

Note: Diagram above does not take into account inline hardpoints (mounting positions seated one-behind-the-other).


Mi-17 (Hip-H) - Base Series Designation.
Mi-17-1
Mi-17-1M
Mi-17-1V
Mi-17-1VA
Mi-17-2
Mi-17V-3
Mi-17V-5
Mi-17V-7
Mi-17M
Mi-17MD
Mi-17KF
Mi-17N
Mi-17P
Mi-17PG
Mi-17PI
Mi-17PP
Mi-17S
Mi-17AE
Mi-17LPZS
Mi-17Z-2 "Prehrada"


General Assessment
Firepower
Performance
Survivability
Versatility
Impact
Values are derrived from a variety of categories related to the design, overall function, and historical influence of this aircraft in aviation history.
Overall Rating
The overall rating takes into account over 60 individual factors related to this aircraft entry.
76
Rating is out of a possible 100 points.
Firepower Index (BETA)


Inherent combat value taking into account weapons support / versatility, available hardpoints, and total carrying capability.
64.0
View the List
Relative Maximum Speed
Hi: 200mph
Lo: 100mph
This entry's maximum listed speed (158mph).

Graph average of 150 miles-per-hour.
City-to-City Ranges
NYC

  LON
LON

  PAR
PAR

  BER
BER

  MOS
MOS

  TOK
TOK

  SYD
SYD

  LAX
LAX

  NYC
Mil Mi-17 (Hip-H) operational range when compared to distances between major cities (in KM).
Max Altitude Visualization
Small airplane graphic
Design Balance
The three qualities reflected above are altitude, speed, and range.
Aviation Era Span
Pie graph section
Pie graph section
Showcasing era cross-over of this aircraft design.
Unit Production (12,000)
12000
36183
44000
Compared against Ilyushin IL-2 (military) and Cessna 172 (civilian).
>>

Military lapel ribbon for Operation Allied Force
Military lapel ribbon for the Arab-Israeli War
Military lapel ribbon for the Battle of Britain
Military lapel ribbon for the Battle of Midway
Military lapel ribbon for the Berlin Airlift
Military lapel ribbon for the Chaco War
Military lapel ribbon for the Cold War
Military lapel ribbon for the Cuban Missile Crisis
Military lapel ribbon for pioneering aircraft
Military lapel ribbon for the Falklands War
Military lapel ribbon for the French-Indochina War
Military lapel ribbon for the Golden Age of Flight
Military lapel ribbon for the 1991 Gulf War
Military lapel ribbon for the Indo-Pak Wars
Military lapel ribbon for the Iran-Iraq War
Military lapel ribbon for the Korean War
Military lapel ribbon for the 1982 Lebanon War
Military lapel ribbon for the Malayan Emergency
Military lapel ribbon representing modern aircraft
Military lapel ribbon for the attack on Pearl Harbor
Military lapel ribbon for the Six Day War
Military lapel ribbon for the Soviet-Afghan War
Military lapel ribbon for the Spanish Civil War
Military lapel ribbon for the Suez Crisis
Military lapel ribbon for the Ukranian-Russian War
Military lapel ribbon for the Vietnam War
Military lapel ribbon for Warsaw Pact of the Cold War-era
Military lapel ribbon for the WASP (WW2)
Military lapel ribbon for the World War 1
Military lapel ribbon for the World War 2
Military lapel ribbon for the Yom Kippur War
Military lapel ribbon for experimental x-plane aircraft


Ribbon graphics not necessarily indicative of actual historical campaign ribbons. Ribbons are clickable to their respective aerial campaigns / operations / aviation periods.
